BDCOM S1500-16P2G2S 16-Port Gigabit Unmanaged PoE Switch

BDCOM S1500-16P2G2S 16-Port Unmanaged PoE Switch

The BDCOM S1500-16P2G2S 16-port Gigabit unmanaged PoE switch is designed for network devices requiring efficient power and data transmission. The BDCOM 16 Port PoE Switch provides 16 Gigabit PoE+ ports, two Gigabit RJ45 uplinks, and two Gigabit SFP uplinks. The Gigabit Unmanaged PoE Switch delivers a 40 Gbps switching capacity, supporting smooth network traffic across connected devices.

PoE+ Power Distribution

With 802.3af/at support, each PoE port delivers up to 30W for compatible network equipment. This Unmanaged Network Switch 185W PoE budget supports multiple powered devices, including IP cameras, access points, and VoIP equipment. A built-in AC 100-240V power supply simplifies deployment without requiring an external power adapter. The BDCOM S1500-16P2G2S PoE Ethernet Switch provides a reliable power distribution option for PoE-based installations.

DIP Working Modes

The DIP function offers Default, VLAN, and CCTV operating modes for different network requirements. CCTV mode extends selected ports from 9 to 16, while VLAN mode provides port isolation across connected devices. These features help separate traffic and improve network management for surveillance environments. The BDCOM S1500-16P2G2S 16-Port Gigabit Switch also includes 4KV lightning protection for added electrical protection during installation.

Fanless Design and Installation

A fanless design supports quieter operation while reducing mechanical components inside the PoE Network Switch. The unit operates from 0°C to 50°C with 10%-90% non-condensing humidity. Its 440 × 204 × 44mm dimensions support desktop or rack-mounted installation in different networking spaces. Overall, the BDCOM S1500-16P2G2S CCTV PoE Switch combines Gigabit connectivity, PoE+ power, flexible DIP modes, and compact installation for network deployments.
