Gigalink RR-GM41D 4 Port PoE Switch

The Gigalink RR-GM41D PoE Switch provides four 10/100Mbps PoE ports and one 10/100Mbps uplink ports. All four PoE ports support the IEEE 802.3af and IEEE 802.3at standards. This network switch delivering up to 15.4W or 30W per port depending on connected device requirements.

The total power budget of the Gigalink RR-GM41D PoE Switch reaches 65W at 52V 1.5A, supporting multiple powered devices simultaneously without power supply concerns. Each PoE port uses end-span power delivery with both 1/2+, 3/6- and 4/5+, 7/8- power pin configurations for broad device compatibility. The Gigalink 4 Port Switch extends PoE power and data transmission up to 150 meters, making it ideal for long-distance IP camera and access point deployments.

All ports support MDI/MDIX auto flip and auto-negotiation, eliminating the need for crossover cables during network installation. The Gigalink RR-GM41D 4 Port PoE Switch has store-and-forward switching mode ensures error-free data packet forwarding across all connected network ports without packet loss. The switch supports IEEE 802.3x full-duplex flow control and backpressure for half-duplex mode to prevent network congestion effectively.

Forwarding rates reach 14,880 PPS for 10BASE-T and 14,800 PPS for 100BASE-TX connections across each individual port. The Gigalink PoE Switch features a 20Gbps total switch capacity and a MAC address table supporting up to 1K entries for efficient network management. Automatic MAC address learning and aging keeps the address table current without requiring manual administrator intervention.

The Gigalink Network Switch operates reliably across working temperatures from -10°C to 55°C for stable indoor and outdoor enclosure deployment. The Gigalink RR-GM41D 4 Port PoE Switch has LED indicators per port display LINK/ACT status, 100Mbps connection speed, PoE power status, and overall power health clearly.
