Gigalink RR-GQ82A 8 Port PoE Switch

The Gigalink RR-GQ82A 8 Port PoE Switch is built for demanding IP camera, wireless access point, IP phone, and computer network deployments. This Switch provides eight 10/100Mbps PoE ports and two 100/1000Mbps uplink ports for flexible, scalable network connectivity across small to medium installations. All eight PoE ports fully comply with IEEE 802.3af and IEEE 802.3at standards, supporting output power of 15.4W or 30W per port depending on the connected device's power requirements.

Each port delivers a maximum PoE power output of 30W, with both 1/2+, 3/6- and 4/5+, 7/8- power pin configurations supported for broad end-span device compatibility. The Gigalink RR-GQ82A PoE Switch operates on a total power budget of 120W at 52V and 2.3A, accommodating multiple high-power devices simultaneously without supply constraints. PoE and data transmission both extend up to 250 meters over Class 5 or above unshielded twisted pair cabling for long-distance installations.

All ports support MDI/MDIX auto flip and auto-negotiation, eliminating crossover cable requirements and simplifying physical network installation significantly. The Gigalink 8 Port Switch uses store-and-forward switching mode for error-free data packet delivery across all connected network ports without packet loss. A forwarding rate of 14,800 PPS per port at 100BASE-TX ensures efficient, high-speed data handling throughout the entire network segment.

The Gigalink RR-GQ82A 8 Port PoE Switch has total switch capacity reaches 10Gbps, providing ample internal bandwidth for simultaneous multi-port high-traffic network operation. A 2K MAC address table supports automatic learning and aging for efficient, self-maintaining network address management without administrator intervention.

IEEE 802.3x full-duplex flow control and half-duplex backpressure prevent network congestion across all active port connections. The Gigalink RR-GQ82A 8 Port Switch has Per-port LED indicators display LINK/ACT status, 100Mbps connection speed, PoE power status, and overall power health clearly at a glance. The Gigalink Network Switch operates reliably across working temperatures from -10°C to 55°C for stable deployment in varied indoor environments.
