Hikvision DS-8632NI-K8 Embedded 4K NVR

Professional and Reliable Dual-OS design to ensure high reliability of system running. ANR technology to enhance the storage reliability when the network is disconnected

HD Input

H.265/ H.265+/H.264//H.264+/MPEG4 video formats.Connectable to the third-party network cameras Up to 32 IP cameras can be connected.

Recording at up to 8 MP resolution. Supports live view, storage, and playback of the connected camera at up to 8 MP resolution.

HD Output HDMI1/VGA1 and HDMI2/VGA2 independent outputs provided. HDMI1 Video output at up to 4K (3840 × 2160) resolution

HD Storage Up to 8 SATA interfaces and 1 eSATA interface connectable for recording and backup. Storage space effectively saved by 50% to 70% with the use of H.264+ decoding format.

HD Transmission 2 self-adaptive 10 M/100 M/1000 Mbps network interfaces, and two working modes are configurable: multi-address

and network fault tolerance.

Various Applications

Centralized management of IP cameras, including configuration, information import/export, real-time information display, two-way audio, upgrade, etc.

Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can

be realized.

• VCA detection alarm is supported
• Instant playback for assigned channel during multi-channel display mode
• Smart search for the selected area in the video; and smart playback to improve the playback efficiency
• Supports HDD quota and group modes; different capacity can be assigned to different channels
