Huawei eKitEngine S110-24T2SR 24 Port Gigabit Unmanaged Switch

The Huawei eKitEngine S110-24T2SR is a 24-port Gigabit unmanaged switch with 24 10/100/1000BASE-T downlink ports and 2 GE SFP uplink ports, meeting a variety of connectivity requirements. When the switch is in standard mode, it can disable flow control, support uplink aggregation, and support port isolation, all of which maximize network efficiency. The network switch has effective heat management, dissipating heat at a maximum of 58 BTU/hour and an average of 54.6 BTU/hour. With an availability rate surpassing 99.999% and a Mean Time to Repair (MTTR) of 2 hours, it is built for high availability. Because the switch is fanless, it runs quietly, with noise levels under 30 dB for acoustic power and 20 dB for acoustic pressure. The Huawei eKitEngine S110-24T2SR 24 Port Gigabit Unmanaged Switch is suitable for a range of weather situations. It can operate at temperatures between 0°C and 40°C and up to 1800 meters in altitude. For every 220 meters gained in altitude between 1800 and 5000 meters, the maximum operating temperature drops by 1°C. It features a storage temperature range of -40°C to 70°C and can function dependably in non-condensing relative humidity levels of 5% to 95%. The Huawei eKitEngine S110-24T2SR 24 Port Gigabit Unmanaged Switch boasts an IP20 ingress protection grade, which guarantees durability against dust and water and is built for long-term operation at elevations up to 5000 meters. It is powered by an AC built-in power source and has a maximum input current of 0.8 A. It supports an input voltage range of 90 V AC to 300 V AC at frequencies of 47 Hz to 63 Hz. Strong surge protection is included in the device; it can handle surges up to ±1 kV on service ports and up to ±6 kV on the power supply in both differential and common modes.
