Huawei eKitEngine S310-48T4X 48 Port Gigabit Managed Switch

The Huawei eKitEngine S310-48T4X 48-port Gigabit managed switch is designed to provide high-performance networking solutions. It offers flexible connectivity options with 48 downlink 10/100/1000BASE-T ports and 4 uplink 10GE SFP+ ports. The switch manages heavy data traffic well, with a substantial switching capacity of 176 Gbps and a packet forwarding rate of 131 Mpps. With an average output of 126.07 BTU/hour and a maximum of 151.15 BTU/hour, heat dissipation is efficiently controlled. This is made possible by a single fan module with intelligent speed adjustment. At room temperature, the Huawei eKitEngine S310-48T4X 48-port Gigabit managed switch produces 46.6 dB(A) of acoustic power and 34.6 dB(A) of acoustic pressure, with minimal operating noise. With an availability rate higher than 0.99999 and a mean time to repair (MTTR) of two hours, the switch guarantees great dependability. With particular adaptations for higher elevations, its operational range is flexible, operating between -5°C and 50°C at altitudes up to 1800 meters. The 48-port Gigabit managed switch, Huawei eKitEngine S310-48T4X, can operate seamlessly in a range of humidity settings, including non-condensing 5% to 95% RH, and storage temperatures, which span from -40°C to 70°C. A built-in AC mode that can handle an input voltage range of 90 to 290 V AC at 45 to 65 Hz and a maximum input current of 1.6 A is used to supply power. The switch has an RJ45 console interface for management and 1 GB of physical flash memory. With sturdy construction and strong surge protection, the Huawei eKitEngine S310-48T4X 48-port Gigabit managed switch provides considerable protection for service ports at ±7 kV and power supply protection in both differential and common modes at ±6 kV. The switch uses air cooling with a left-to-right airflow and has an IP20 ingress protection level. It is certified for EMC, safety, and manufacturing standards.
