TRENDnet TEG-S80ES 8-Port EdgeSmart Gigabit Switch
Model: TEG-S80ESItem #: trendnet-teg-s80es-8-port-gigabit-switch
৳7,000৳7,500Save 7%
In stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- 2 Year Warranty
Overview
The TRENDnet TEG-S80ES is an 8-port EdgeSmart Gigabit switch optimized for high-performance networking. Its simple web-based interface enables users to setup VLANs, Quality of Service (QoS), IGMP snooping, and static link aggregation for better network traffic. This TRENDnet TEG-S80ES 8-Port Gigabit Switch supports IEEE 802.1p CoS and queue scheduling to provide smooth data priority for important applications. With a 16Gbps switching capacity and full-duplex Gigabit rates of up to 2000Mbps per port, it provides efficient and stable connectivity for home offices, small enterprises, and VoIP applications. It also supports dedicated Voice VLAN. The TRENDnet TEG-S80ES Gigabit Switch is designed for network efficiency, including IEEE 802.1d STP and 802.1w RSTP support for spanning tree protocols, which avoid network loops and improve dependability. It supports static link aggregation for up to two groups, which optimizes bandwidth in high-traffic environments. The TRENDnet TEG-S80ES EdgeSmart Switch provides port-based VLAN, 802.1Q tagged VLAN, and private VLAN, with up to 32 VLAN groups for secure and separated network communication. In addition, IGMP Snooping v1/2/3 with multicast filtering improves performance for streaming and other bandwidth-intensive applications. The TRENDnet TEG-S80ES 8-Port EdgeSmart Gigabit Switch runs quietly and may be wall-mounted for flexible installation. It includes a 4K MAC address table, a 192KB RAM buffer, and can handle jumbo frames up to 9KB for faster data transmission. Storm control and loopback detection reduce network congestion and security risks, while port mirroring enables efficient network monitoring. The TRENDnet TEG-S80ES 8-Port EdgeSmart Gigabit Switch also supports bandwidth control per port, with a minimum rate restriction of 8Kbps for precise traffic management. It supports the 802.3az power-saving mode, which lowers energy usage when network demand is low. Its NDAA and TAA compliance make it appropriate for government and enterprise use.
Specifications
- Warranty
- 2 Year
- Highlights — Model
- TEG-S80ES
- Main Feature — Port
- 8 x Gigabit ports
- Main Feature — Type
- Gigabit EdgeSmart Switch
- Highlights — Interface
- 8 x Gigabit ports
- Hardware Features — LED
- LED indicators
- Hardware Features — Weight
- 317g (11.18 oz.)
- Main Feature — Environment
- Operating Temperature: 0° – 40° C (32° – 104° F); Operating Humidity: Max. 90% non-condensing
Show all 16 specificationsShow fewer
- Highlights — Forwarding rate
- 11.9Mpps (64-byte packet size)
- Highlights — Switching Capacity
- 16Gbps
- Main Feature — Network Standard
- IEEE 802.1d; IEEE 802.1w; IEEE 802.1p; IEEE 802.1Q; IEEE 802.3; IEEE 802.3u; IEEE 802.3x; IEEE 802.3ab; IEEE 802.3az
- Hardware Features — Power Supply
- Input: 100 – 240V AC, 50/60Hz, 0.2A; Output: 5V DC, 1A external power adapter; Max consumption: 4.94W
- Main Feature — MAC Address Table
- 4K entries
- Main Feature — Advanced Functions
- Management ; HTTP Web based GUI; SNMP v1, v2c; Cable diagnostic test; Backup/Restore Configuration; Upload Firmware; Spanning Tree ; IEEE 802.1d STP (spanning tree protocol); IEEE 802.1w RSTP (rapid spanning tree protocol); Link Aggregation ; Static link aggregation (up to 2 groups); Quality of Service (QoS) ; Port-based QoS; 802.1p Class of Service (CoS); Bandwidth Control/Rate Limiting per port (Min. Limit: 8Kbps); Queue Scheduling: Strict Priority (SP), Weighted Fair Queueing (WFQ); VLAN ; Port-based VLAN; 802.1Q Tagged VLAN; Up to 32 VLAN groups, ID Range 1-4094; Private VLAN; Asymmetric VLAN; Voice VLAN (5 user defined OUIs); Multicast ; IGMP Snooping v1/2/3; Block unknown multicast source; Up to 32 multicast groups; Port Mirror ; One to one; Many to one; Storm Control ; Broadcast (Min. Limit: 8Kbps); Multicast (Min. Limit: 8Kbps); Loopback Detection; Special Features ; Enable/disable 802.3az Power Saving; Wall mountable
- Main Feature — Data Transmission Rate
- Ethernet: 10Mbps (half duplex), 20Mbps (full duplex); Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex); Gigabit Ethernet: 2000Mbps (full duplex); Switch fabric: 16Gbps; RAM buffer: 192KB; Jumbo Frames: 9KB; Forwarding rate: 11.9Mpps (64-byte packet size)
- Hardware Features — Dimensions (L x W x H)
- 145 x 82 x 28mm (5.7 x 3.22 x 1.1 in.)
