XENTHRA XN-H81M-VH 4th Gen mATX Motherboard
1600 / 1333 / 1066 MHz · Micro-ATX (180 mm x 216 mm) · Intel B85 Express Chipset
৳4,200৳4,500Save 7%
In stock
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Shop all MSI products
MSI B760M GAMING PLUS WIFI 6E mATX Motherboard
Model: B760M GAMING PLUSItem #: msi-b760m-gaming-plus-motherboard
৳18,900
Out of stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- INTEL B760 Chipset
- 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz RAM type
- m-ATX; 243.84mmx243.84mm Form factor
Overview
The MSI B760M GAMING PLUS WIFI 6E mATX Motherboard is a flexible and high-performance option for enthusiasts and gamers alike. This motherboard provides a powerful and efficient computing experience by being compatible with 14th, 13th, and 12th Gen Intel Core, Pentium, and Celeron processors utilizing the LGA 1700 socket. Its four DDR5 RAM slots provide a maximum capacity of 192GB and an overclocking potential of 6800+MHz (OC), giving the speed and responsiveness required for demanding activities. The motherboard has two HDMI2.1 connections and delivers excellent graphics output, enabling the newest display technologies for a better visual experience. The presence of Dual 2.5G LAN, in conjunction with the most recent Wi-Fi 6E technology, offers smooth and high-speed networking, meeting the demands of online gaming and multimedia streaming. The MSI B760M GAMING PLUS WIFI 6E mATX Motherboard includes Dual DisplayPort 1.4, which increases display versatility and supports high-resolution visuals. This makes it an excellent solution for consumers that want a multi-monitor arrangement or high visual clarity. The MSI B760M GAMING PLUS WIFI 6E mATX Motherboard strikes a mix between performance and features, making it a good choice for gamers and people searching for a compact yet powerful system. This motherboard meets the diversified demands of modern computing by supporting the most recent technologies in networking and graphics output.
Specifications
- Chipset
- INTEL B760
- RAM type
- 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
- Form factor
- m-ATX; 243.84mmx243.84mm
- Memory — Type
- DDR5
- Memory — Slots
- 4
- Highlights — Model
- B760M GAMING PLUS
- Graphics — Graphics
- 2x HDMI; Support HDMI 2.1, maximum resolution of 4K 60Hz
- Expansion Slots — PCI
- 2x PCI-E x16 slot; 1x PCI-E x1 slot; PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU); PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset); PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
Show all 25 specificationsShow fewer
- Highlights — Features
- 2.5G LAN, Wi-Fi 6E, Dual DisplayPort1. 4
- Memory — Maximum Memory
- 192GB
- Connector & Ports — RAID
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices;
- Basic Information — Audio
- Realtek ALC897 Codec; 7.1-Channel High Definition Audio
- Connector & Ports — Audio
- 7.1-Channel High Definition Audio;
- Others — Special Features
- 1x EZ LED Control switch; 4x EZ Debug LED; 1x 2-Digit Debug Code LED
- Highlights — Supported RAM
- 4x DDR5, Max 192GB, 6800+MHz (OC)
- Connector & Ports — USB (s)
- 2x USB 2.0 (Rear); 4x USB 2.0 (Front); 2x USB 3.2 Gen1 Type A (Rear); 4x USB 3.2 Gen1 Type A (Front); 1x USB 3.2 Gen1 Type C (Front); 2x USB 3.2 Gen2 Type A (Rear)
- Highlights — Graphics Output
- 2x HDMI2.1
- Connector & Ports — LAN Port (s)
- Realtek RTL8125BG 2.5G LAN
- Basic Information — Supported CPU
- Supports 14th/12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors; LGA 1700
- Connector & Ports — Display Port (s)
- 2x DisplayPort 1.4
- Connector & Ports — Supported Storage
- 2x M.2; M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices; M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices; 4x SATA 6G; SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
- Connector & Ports — Internal I/O Ports
- x Power Connector(ATX_PWR); 2x Power Connector(CPU_PWR); 1x CPU Fan; 1x Pump Fan; 2x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 2x Addressable V2 RGB LED connector (JARGB_V2); 1x RGB LED connector(JRGB); 1x TPM pin header(Support TPM 2.0); 4x USB 2.0 ports; 4x USB 3.2 Gen1 Type A ports; 1x USB 3.2 Gen1 Type C ports
- Warranty Information — Manufacturing Warranty
- 3 years
- Connector & Ports — Wireless Communication module
- Intel Wi-Fi 6E; The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps; Supports 802.11 a/ b/ g/ n/ ac/ ax; Supports Bluetooth 5.3, FIPS, FISMA
- Connector & Ports — TPM (Trusted Platform Module )
- 1x TPM pin header(Support TPM 2.0)
Compare with similar products
 This itemMSI B760M GAMING PLUS WIFI 6E mATX Motherboard |  GIGABYTEGIGABYTE B650M D3HP AX DDR5 AM5 Motherboard |  GIGABYTEGIGABYTE B760M D3HP WIFI6 DDR5 mATX Motherboard |  ASRockASRock B760M Pro RS DDR5 mATX Motherboard | |
|---|---|---|---|---|
| Price | ৳18,900 | ৳18,900 | ৳18,900 | ৳18,900 |
| Availability | Out of stock | In stock | In stock | Out of stock |
| Brand | MSI | GIGABYTE | GIGABYTE | ASRock |
| RAM type | 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz | 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules; Dual channel memory architecture; Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules | Support for DDR5 4800/4400 MT/s memory modules; 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules | Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC); Max. capacity of system memory: 256GB; Supports Intel Extreme Memory Profile (XMP) 3.0; ; 1DPC 1R Up to 7200+ MHz (OC), 4800 MHz Natively.; 1DPC 2R Up to 6000+ MHz (OC), 4400 MHz Natively.; 2DPC 1R Up to 5600+ MHz (OC), 4000 MHz Natively.; 2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively. |
| Form factor | m-ATX; 243.84mmx243.84mm | Micro ATX Form Factor; 24.4cm x 24.4cm | Micro ATX Form Factor; 24.4cm x 24.4cm | Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm |
| Chipset | INTEL B760 | AMD B650 | Intel B760 Express Chipset | Intel B760 |
Warranty & returns
Manufacturer warranty
Covered by the manufacturer's official Bangladesh warranty where one applies. The warranty term for this product, when the source lists one, appears in the specifications above.
Dead on arrival
Report a dead-on-arrival unit within 3 days of delivery and we replace it.
Returns
Return an unopened, unused product in its original packaging within 3 days of delivery. Delivery charges are not refundable.
