ASRock B760M Pro-A WiFi DDR5 Micro ATX Motherboard
Model: B760M Pro-A WiFiItem #: asrock-b760m-pro-a-wifi-ddr5-micro-atx-motherboard
৳19,400
Out of stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- Intel B760 Chipset
- Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC); Max. capacity of system memory: 256GB; Supports Intel Extreme Memory Profile (XMP) 3.0; ; 1DPC 1R Up to 7200+ MHz (OC), 4800 MHz Natively. 1DPC 2R Up to 6000+ MHz (OC), 4400 MHz Natively. 2DPC 1R Up to 5600+ MHz (OC), 4000 MHz Natively. 2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively. RAM type
- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
Overview
The ASRock B760M Pro-A WiFi DDR5 Micro ATX Motherboard is a powerful and versatile platform designed to support the latest Intel Core processors, including the 14th Gen, 13th Gen, and 12th Gen with the LGA1700 socket. This ASRock motherboard features a robust 7+1+1 power phase design, utilizing Dr.MOS for efficient VCore and GT performance, ensuring stable and reliable power delivery. With four DDR5 DIMM slots, it supports dual-channel memory up to 7200+ MHz (OC), providing significant improvements in data transfer rates and overall system responsiveness. The motherboard includes one PCIe 5.0 x16 slot and one PCIe 3.0 x16 slot, offering flexibility for various high-speed components and peripherals. For storage, the ASRock B760M Pro-A WiFi features four SATA3 ports and three Hyper M.2 slots (PCIe Gen4x4), providing ample space for high-speed SSDs and traditional hard drives. Connectivity is enhanced with Dragon 2.5G LAN and Killer 802.11ax WiFi 6E, ensuring fast and reliable network performance. The motherboard also includes a variety of USB ports, such as USB 3.2 Gen1 Type-C, USB 3.2 Gen1 Type-A, and USB 2.0 ports for versatile connectivity options. Advanced audio capabilities with 7.1 CH HD Audio (Realtek ALC897 Audio Codec) deliver immersive sound quality for gaming and multimedia. The ASRock B760M Pro-A WiFi also supports ASRock Auto Driver Installer, simplifying the setup process. Its sleek design, combined with a 6-layer PCB and high-quality components, ensures durability and efficient heat dissipation, making it a reliable choice for any high-performance build. Whether you're looking for a gaming motherboard, a content creation platform, or a professional workstation, the ASRock B760M Pro-A WiFi DDR5 Micro ATX Motherboard offers the features and performance needed to excel in any task.
Specifications
- Chipset
- Intel B760
- RAM type
- Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC); Max. capacity of system memory: 256GB; Supports Intel Extreme Memory Profile (XMP) 3.0; ; 1DPC 1R Up to 7200+ MHz (OC), 4800 MHz Natively. 1DPC 2R Up to 6000+ MHz (OC), 4400 MHz Natively. 2DPC 1R Up to 5600+ MHz (OC), 4000 MHz Natively. 2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively.
- Form factor
- Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm
- Memory — Type
- DDR5
- Memory — Slots
- 4
- Highlights — Model
- B760M Pro-A WiFi
- Graphics — Graphics
- - Intel Xe Graphics Architecture (Gen 12); - 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz; - 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz; ; * Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors that are GPU integrated.
- Expansion Slots — PCI
- CPU:; - 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode; Chipset:; - 1 x PCIe 3.0 x16 Slot (PCIE2), supports x4 mode; - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT); - Supports AMD CrossFire
Show all 27 specificationsShow fewer
- Highlights — Features
- 2.5 Gigabit LAN, Wi-Fi 6E, Bluetooth 5.3
- Memory — Maximum Memory
- 256GB
- Basic Information — BIOS
- 128Mb AMI UEFI Legal BIOS with GUI support
- Connector & Ports — HDMI
- 1x HDMI
- Connector & Ports — RAID
- - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Basic Information — Audio
- 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
- Others — Bundled Software
- Software; - ASRock Motherboard Utility (A-Tuning); - ASRock Dragon 2.5G LAN Software; - ASRock Polychrome SYNC; UEFI; - ASRock EZ Mode; - ASRock Full HD UEFI; - ASRock My Favorites in UEFI; - ASRock Auto Driver Installer; - ASRock Instant Flash; - ASRock Easy RAID Installer
- Others — Special Features
- Superb Productivity; - PCIe Gen5 (Graphics); - Dual Channel DDR5; Rock-Solid Durability; - 7+1+1 Power Phase, Dr.MOS for VCore+GT; Ultrafast Connectivity; - 2.5G LAN; EZ Update; - ASRock Auto Driver Installer; EZ Troubleshooter; - ASRock Post Status Checker
- Highlights — Supported RAM
- 4x DDR5, Max 256GB 7200+(OC)
- Connector & Ports — USB (s)
- Chipset:; - 2 x USB 3.2 Gen1 Type-C (1 Rear, 1 Front); - 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front); - 6 x USB 2.0 (2 Rear, 4 Front); * All USB ports support ESD Protection
- Highlights — Graphics Output
- 1x HDMI, 1x DisplayPort
- Connector & Ports — LAN Port (s)
- - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s; - Dragon RTL8125BG; - Supports Dragon 2.5G LAN Software; - Smart Auto Adjust Bandwidth Control; - Visual User-Friendly UI; - Visual Network Usage Statistics; - Optimized Default Settings for Game, Browser, and Streaming Modes; - User Customized Priority Control
- Basic Information — Supported CPU
- Supports 14th, 13th & 12th Gen Intel Core Processors (LGA1700); Supports Intel Hybrid Technology; Supports Intel Turbo Boost Max 3.0 Technology; Supports Intel Thermal Velocity Boost (TVB); Supports Intel Adaptive Boost Technology (ABT)
- Connector & Ports — Display Port (s)
- 1x DisplayPort
- Connector & Ports — Supported Storage
- CPU:; - 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode*; Chipset:; - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*; - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*; - 4 x SATA3 6.0 Gb/s Connectors; ; * Supports Intel Volume Management Device (VMD); Supports NVMe SSD as boot disks
- Connector & Ports — Internal I/O Ports
- - 2 x Antenna Mounting Points; - 1 x PS/2 Mouse/Keyboard Port; - 1 x HDMI Port; - 1 x DisplayPort 1.4; - 1 x USB 3.2 Gen1 Type-C Port; - 3 x USB 3.2 Gen1 Type-A Ports; - 2 x USB 2.0 Ports; - 1 x RJ-45 LAN Port; - HD Audio Jacks: Line in / Front Speaker / Microphone; ; Connector; - 1 x Chassis Intrusion and Speaker Header; - 1 x RGB LED Header*; - 3 x Addressable LED Headers**; - 1 x CPU Fan Connector (4-pin)***; - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****; - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****; - 1 x 24 pin ATX Power Connector; - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector); - 1 x Front Panel Audio Connector; - 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card); - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports); - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports); - 1 x Front Panel Type C USB 3.2 Gen1 Header
- Warranty Information — Manufacturing Warranty
- 3 years Warranty
- Connector & Ports — Wireless Communication module
- - 802.11axe Wi-Fi 6E Module; - Supports IEEE 802.11a/b/g/n/ac/ax/axe; - Supports Dual-Band 2x2 160MHz with extended 6GHz band* support; - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology; - Supports Bluetooth 5.3 + High speed class II; - Supports MU-MIMO; - Supports Killer LAN Software
- Connector & Ports — TPM (Trusted Platform Module )
- - 1 x SPI TPM Header
Compare with similar products
 This itemASRock B760M Pro-A WiFi DDR5 Micro ATX Motherboard |  GIGABYTEGIGABYTE B760M GAMING X AX DDR5 mATX Motherboard |  MSIMSI B840M GAMING WIFI6E AM5 mATX Motherboard |  GIGABYTEGIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard | |
|---|---|---|---|---|
| Price | ৳19,400 | ৳19,300 | ৳19,400 | ৳19,500 |
| Availability | Out of stock | Out of stock | Out of stock | Out of stock |
| Brand | ASRock | GIGABYTE | MSI | GIGABYTE |
| RAM type | Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC); Max. capacity of system memory: 256GB; Supports Intel Extreme Memory Profile (XMP) 3.0; ; 1DPC 1R Up to 7200+ MHz (OC), 4800 MHz Natively. 1DPC 2R Up to 6000+ MHz (OC), 4400 MHz Natively. 2DPC 1R Up to 5600+ MHz (OC), 4000 MHz Natively. 2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively. | Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules | Memory Support DDR5 8000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s; Ryzen 9000 Series Processors max. overclocking frequency:; 1DPC 1R Max speed up to 8000+ MT/s; 1DPC 2R Max speed up to 7200+ MT/s; Supports AMD POR Speed and JEDEC Speed; Supports Memory Overclocking and AMD EXPOTM; Supports Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM, Clock Driver bypass mode only | 14th and 13th Generation Intel Core i9/i7 Processors:; Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.)/ 5600/5200/4800/4400 MT/s memory modules; 13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:; Support for DDR5 4800/4400 MT/s memory modules; 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules |
| Form factor | Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm | Micro ATX Form Factor; 24.4cm x 24.4cm | mATX; 226mmx243.84mm | Micro ATX Form Factor; 24.4cm x 24.4cm |
| Chipset | Intel B760 | Intel B760 Express Chipset | AMD B840 | Intel B760 Express Chipset |
| M.2 slots | — | — | 2 | 1 |
