GIGABYTE B760M AORUS ELITE DDR5 mATX Motherboard

Name: GIGABYTE B760M AORUS ELITE DDR5 mATX Motherboard
Brand: GIGABYTE
Price: 23000 BDT
Availability: OutOfStock

Model: B760M AORUS ELITEItem #: gigabyte-b760m-aorus-elite-motherboard

৳23,000

Out of stockverified 22 Sept 2026

Ordering is paused

We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.

Delivery

Inside Dhaka: ৳60 · 1–2 days
Outside Dhaka: ৳120 · 2–4 days

Sold by Micro

Key highlights

Intel B760 Express Chipset
Support for DDR5 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules RAM type
Micro ATX Form Factor; 24.4cm x 24.4cm

Overview

The GIGABYTE B760M AORUS ELITE Motherboard is a performance and feature powerhouse intended for Intel Socket LGA 1700 processors, with support for 14th, 13th, and 12th generation Intel Core CPUs. The Twin 12*+1+1 Phases Digital VRM Solution on this motherboard is its highlight feature, providing steady and efficient power supply for better performance and overclocking capabilities. It also features 4*SMD DIMM slots with XMP 3.0 Memory Module compatibility for enhanced multitasking and gaming performance. The motherboard includes two PCIe 4.0 x4 M.2 ports, allowing for high-speed NVMe SSDs for fast data access and startup times. An M.2 Thermal Guard is included in the advanced thermal design to enable appropriate cooling for VRM components and M.2 SSDs, reducing thermal throttling. The EZ-Latch Plus M.2 Connectors have a quick-release and screwless design that allows for simple SSD installation and changing. It has a 2.5GbE LAN connector for lightning-fast network access, as well as a variety of connectivity choices such as front USB-C 10Gb/s and rear USB-C 20Gb/s ports, as well as DP and HDMI display capabilities. The Smart Fan 6 system has numerous temperature sensors and hybrid fan headers, as well as a FAN STOP feature, to optimize cooling and reduce noise. Finally, the Q-Flash Plus function enables BIOS upgrades without the need to install the CPU, RAM, or graphics card, greatly simplifying the update procedure. In conclusion, the GIGABYTE B760M AORUS ELITE Motherboard has an excellent set of features as well as top-tier performance, appealing to gamers, content makers, and power users alike.

Buy GIGABYTE B760M AORUS ELITE DDR5 mATX Motherboard from the best Motherboard Shop in BD

Specifications

Chipset: Intel B760 Express Chipset
RAM type: Support for DDR5 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules
Form factor: Micro ATX Form Factor; 24.4cm x 24.4cm
Memory — Type: DDR5
Memory — Slots: 4
Highlights — Model: B760M AORUS ELITE
Graphics — Graphics: Integrated Graphics Processor-Intel HD Graphics support:; 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz; 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
Expansion Slots — PCI: CPU:; 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16); Chipset:; 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4); Support for AMD CrossFireX technology

Show all 27 specifications

Highlights — Features: Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Memory — Maximum Memory: up to 192 GB (48 GB single DIMM capacity)
Basic Information — BIOS: 1 x 256 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Connector & Ports — HDMI: 1x HDMI
Connector & Ports — RAID: RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Basic Information — Audio: Realtek Audio CODEC; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out
Connector & Ports — Audio: 1 x front panel audio header; 2 x audio jacks
Others — Bundled Software: Norton Internet Security (OEM version); LAN bandwidth management software
Others — Special Features: Support for GIGABYTE Control Center (GCC); Support for Q-Flash; Support for Q-Flash Plus
Highlights — Supported RAM: 4x DDR5, Max 192GB 7600(OC)
Connector & Ports — USB (s): 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2x2 support; 1 x USB Type-C port with USB 3.2 Gen 2 support, available through the internal USB header; 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel; 1 x USB 3.2 Gen 1 port on the back panel; 4 x USB 2.0/1.1 ports available through the internal USB headers; Chipset+USB 3.2 Gen 1 Hub:; 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header); Chipset+USB 2.0 Hub:; 4 x USB 2.0/1.1 ports on the back panel
Highlights — Graphics Output: 1x HDMI, 1x DisplayPort
Connector & Ports — LAN Port (s): Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Basic Information — Supported CPU: LGA1700 socket: Support for the 14th 13th and 12th Generation Intel Core,; Pentium Gold and Celeron Processors; L3 cache varies with the CPU
Connector & Ports — Display Port (s): 1x DisplayPort
Connector & Ports — Supported Storage: CPU:; 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU); Chipset:; 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB); 4 x SATA 6Gb/s connectors
Connector & Ports — Internal I/O Ports: 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x 4-pin ATX 12V power connector; 1 x CPU fan header; 3 x system fan headers; 2 x addressable LED strip headers; 2 x RGB LED strip headers; 2 x M.2 Socket 3 connectors; 4 x SATA 6Gb/s connectors; 1 x front panel header; 1 x front panel audio header; 1 x USB Type-C header, with USB 3.2 Gen 2 support; 1 x USB 3.2 Gen 1 header; 2 x USB 2.0/1.1 headers; 2 x Thunderbolt add-in card connectors; 1 x Q-Flash Plus button; 1 x reset button; 1 x reset jumper; 1 x Clear CMOS jumper
Warranty Information — Manufacturing Warranty: 3 years
Connector & Ports — TPM (Trusted Platform Module ): 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
