MSI B860 GAMING PLUS WIFI LGA 1851 ATX Motherboard

Name: MSI B860 GAMING PLUS WIFI LGA 1851 ATX Motherboard
Brand: Asus
Price: 26700 BDT
Availability: OutOfStock

Model: B860 GAMING PLUS WIFIItem #: msi-b860-gaming-plus-wifi-atx-motherboard

৳26,700

Out of stockverified 22 Sept 2026

Ordering is paused

We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.

Delivery

Inside Dhaka: ৳60 · 1–2 days
Outside Dhaka: ৳120 · 2–4 days

Sold by Micro

Key highlights

INTEL B860 Chipset
3 M.2 slots
Memory Support 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 8800+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 6400+ MT/s; • 2DPC 2R Max speed up to 5600+ MT/s; ; Supports Intel POR Speed and JEDEC Speed; Supports Memory Overclocking and Intel XMP 3.0; Supports Dual-Controller Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM RAM type
ATX Form Factor; 243.84mmx304.8mm

Overview

Introducing the MSI B860 GAMING PLUS WIFI Motherboard, a unique MSI motherboard built for discerning gamers and professionals that need unrivaled performance, reliable connection, and numerous customization possibilities. As a premium MSI Intel Motherboard, it is based on the Intel B860 chipset and supports Intel Core Ultra Processors via the LGA 1851 socket, allowing users to harness top-tier processing power as well as DDR5 memory speeds of up to 8600+ MT/s across four UDIMM slots for smooth multitasking and dynamic overclocking. This MSI 860 motherboard offers versatile storage choices with several M.2 slots, including a flagship PCIe 5.0 x4 slot for cutting-edge NVMe SSDs and additional PCIe 4.0 slots, as well as four SATA 6Gb/s connectors, making it adaptable to a wide range of storage requirements. This MSI WiFi Motherboard features Intel Wi-Fi 7 technology and a high-speed Realtek Intel Killer LAN connection (up to 5Gbps), providing robust and speedy connectivity for home and professional installations. With a strong 12+1+1+1 phase VRM that includes MSI's patented Core Boost technology and superior cooling solutions such as the EZ M.2 Shield Frozr II, this board maintains even the most demanding gaming sessions and strenuous workloads within safe operating temperatures. Enhanced connectivity choices, such as a dedicated Thunderbolt 4 port via USB Type-C and a variety of display outputs, including HDMI 2.1 and DisplayPort 1.4, add to its multimedia capabilities. The MSI B860 GAMING PLUS WIFI Motherboard, which combines these innovative features with a sleek, gamer-centric design, RGB customization, and durable, steel-reinforced PCIe slots, is a future-proof solution that redefines modern computing, delivering a harmonious blend of performance, efficiency, and next-gen connectivity suitable for both gaming rigs and professional workstations.

Specifications

Chipset: INTEL B860
M.2 slots: 3
RAM type: Memory Support 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 8800+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 6400+ MT/s; • 2DPC 2R Max speed up to 5600+ MT/s; ; Supports Intel POR Speed and JEDEC Speed; Supports Memory Overclocking and Intel XMP 3.0; Supports Dual-Controller Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM
Form factor: ATX Form Factor; 243.84mmx304.8mm
Memory — Type: DDR5
Memory — Slots: 4 x DIMM
Highlights — Model: B860 GAMING PLUS WIFI
Graphics — Graphics: 1x HDMI™; Support HDMI™ 2.1, maximum resolution of 4K 60Hz*; 1x DisplayPort; Support DisplayPort 1.4, maximum resolution of 4K 60Hz*; 1x Type-C DisplayPort; Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz*; *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

Show all 25 specifications

Expansion Slots — PCI: 4x PCI-E x16 slot; PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU); PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset); PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset); PCI_E4 Gen PCIe 4.0 supports up to x1 (From Chipset)
Highlights — Features: 3x M.2, Intel Killer E5000 5Gbps LAN, Wi-Fi 7, Bluetooth 5.4
Memory — Maximum Memory: Maximum Memory Capacity 256GB
Connector & Ports — HDMI: 1x HDMI 2.1
Connector & Ports — RAID: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Basic Information — Audio: Realtek ALC897 Codec; 7.1-Channel High Definition Audio
Connector & Ports — Audio: 1x Front Audio (JAUD)
Highlights — Supported RAM: 4x DDR5, Max 256GB, 8800+ MT/s (OC)
Connector & Ports — USB (s): 4x USB 2.0 (Rear); 4x USB 2.0 (Front); 2x USB 5Gbps Type A (Rear); 4x USB 5Gbps Type A (Front); 2x USB 10Gbps Type A (Rear); 1x USB 10Gbps Type C (Front)
Highlights — Graphics Output: 1x HDMI, 1x DisplayPort, 1x Type-C (Thunderbolt 4)
Connector & Ports — LAN Port (s): Intel Killer E5000 5Gbps LAN
Basic Information — Supported CPU: Supports Intel Core Ultra Processors (Series 2), LGA1851 Socket
Connector & Ports — Display Port (s): 1x DisplayPort 1.4a
Connector & Ports — Supported Storage: 3x M.2; M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices; M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices; M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2 , supports 2280/2260 devices; 4x SATA 6G
Connector & Ports — Internal I/O Ports: 1x Thunderbolt5 card connector(JTBT5, support RTD3); 1x Power Connector(ATX_PWR); 2x Power Connector(CPU_PWR); 1x Power Connector(PCIE_PWR 8pin); 1x CPU Fan; 1x Combo Fan (Pump_Sys Fan); 4x System Fan; 1x EZ Conn-header (JAF_1); 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 1x Tuning Controller connector(JDASH); 2x Addressable V2 RGB LED connector (JARGB_V2); 1x RGB LED connector(JRGB); 1x TPM pin header(Support TPM 2.0); 4x USB 2.0 ports; 4x USB 5Gbps Type A ports; 1x USB 10Gbps Type C ports
Warranty Information — Manufacturing Warranty: 3 Year warranty
Connector & Ports — Wireless Communication module: Intel Killer BE1750x Wi-Fi 7; The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps; Supports 802.11 a/ b/ g/ n/ ac/ ax/ be; ; Supports Bluetooth 5.4**, MLO, 4KQAM
