MSI MEG Z890 ACE LGA 1851 ATX Motherboard

Name: MSI MEG Z890 ACE LGA 1851 ATX Motherboard
Brand: MSI
Price: 103900 BDT
Availability: OutOfStock

Model: MEG Z890 ACEItem #: msi-meg-z890-ace-lga-1851-atx-motherboard

৳103,900

Out of stockverified 22 Sept 2026

Ordering is paused

We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.

Delivery

Inside Dhaka: ৳60 · 1–2 days
Outside Dhaka: ৳120 · 2–4 days

Sold by Micro

Key highlights

INTEL Z890 Chipset
5 M.2 slots
Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 9200+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 4800+ MT/s; • 2DPC 2R Max speed up to 4800+ MT/s RAM type
ATX (243.84mmx304.8mm) Form factor

Overview

The MSI MEG Z890 ACE LGA 1851 ATX Motherboard is a powerhouse designed to unleash the full potential of your gaming and AI PC builds. It supports the latest Intel® Core™ Ultra Processors (Series 2) with the LGA 1851 socket and cutting-edge DDR5 memory, offering dual-channel speeds of up to 9200+ MT/s (OC) for unparalleled performance. Equipped with a 24+2+1+1 Duet Rail Power System and 110A SPS, it ensures stable and efficient power delivery, perfect for overclocking enthusiasts. Advanced connectivity options include ultra-fast Wi-Fi 7, 5G LAN, and high-speed Thunderbolt ports, along with multiple USB 3.2 Gen 1 & 2 ports for versatile connectivity. The motherboard is future-ready with support for PCIe 5.0 and M.2 Gen5 slots, accommodating the latest and future generations of GPUs and storage devices. Built with an 8-layer PCB made of 2oz thickened copper and server-grade materials, the MEG Z890 ACE offers durability and reliability for long-term use. Its advanced cooling solution, featuring multiple heatsinks and fan headers, keeps your system running cool even under heavy loads. Designed with user-friendly features like pre-installed I/O shielding and debug LEDs, it makes the building process easier and more efficient. Whether you're a gamer, content creator, or AI enthusiast, the MSI MEG Z890 ACE LGA 1851 ATX Motherboard provides the ultimate platform for your high-performance PC needs.

Cutting-Edge LGA 1851 Socket and Versatile Ports

The MSI MEG Z890 ACE features the latest LGA 1851 socket, designed to support Intel® Core™ Ultra Processors (Series 2). This new socket ensures compatibility with the most advanced CPUs, providing exceptional performance and efficiency. The motherboard is equipped with a variety of ports, including multiple USB 3.2 Gen 1 & 2 ports, Thunderbolt 4, and 5G LAN, ensuring ultra-fast data transfer and connectivity. Additionally, it supports up to 256GB of DDR5 memory across four DIMM slots, allowing for exceptional multitasking capabilities and future-proofing your system.

Unmatched Speed and Advanced Technology

Embracing the latest technology, the MEG Z890 ACE offers unparalleled speed and performance. It supports DDR5 memory with dual-channel speeds of up to 9200+ MT/s (OC), ensuring blistering performance for gaming and AI applications. The motherboard also features PCIe 5.0 and M.2 Gen5 slots, ready to accommodate the latest GPUs and storage devices. With advanced cooling solutions, including multiple heatsinks and fan headers, the MEG Z890 ACE keeps your system running cool even under heavy loads. The inclusion of Wi-Fi 7 and 10G Super LAN further enhances connectivity, making this motherboard a top choice for high-performance PC builds.

Specifications

Chipset: INTEL Z890
M.2 slots: 5
RAM type: Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 9200+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 4800+ MT/s; • 2DPC 2R Max speed up to 4800+ MT/s
Form factor: ATX (243.84mmx304.8mm)
Memory — Type: DDR5
Memory — Slots: 4x DDR5 UDIMM, Maximum Memory
Highlights — Model: MEG Z890 ACE
Graphics — Graphics: 1x HDMI™; Support HDMITM 2.1 with FRL port, maximum resolution of 8K 60Hz*; 2x Type-C DisplayPort; Thundebolt™ 4 ports supporting DisplayPort 1.4 with HBR3 over USB Type-C, with a maximum resolution of 8K@60Hz*; ; * Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.

Show all 27 specifications

Expansion Slots — PCI: 3x PCI-E x16 slot; PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU); PCI_E2 Gen PCIe 5.0 supports up to x8 (From CPU); PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset); ; • PCI_E1 support manual BIOS adjustment to X8+X8/X8+X4+X4; • PCI_E2 support manual BIOS adjustment to X4+X4; ; * PCI_E1 slot will run at x8 speed when PCI_E2 slot installing device.; ** PCI_E1 slot will run at x8 speed and PCI_E2 slot will run at x4 speed when installing PCIe Gen 5 M.2 device in the M2_4 slot.
Highlights — Features: 5x M.2, Intel Wi-Fi 7
Memory — Maximum Memory: 256GB
Connector & Ports — HDMI: 1x HDMI 21
Connector & Ports — RAID: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices; Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
Basic Information — Audio: Realtek ALC4082 Codec + ESS9219Q Combo DAC/HPA; 7.1-Channel USB High-Performance Audio; Supports S/PDIF output; Supports up to 32-Bit/384 kHz playback on front panel
Connector & Ports — Audio: 1x Front Audio (JAUD)
Others — Special Features: LED FEATURE; 4x EZ Debug LED; 1x EZ Digit Debug LED; 1x EZ LED Control switch
Highlights — Supported RAM: 4x DDR5, Max 256GB 9200 - 6400 (OC) MT/s
Connector & Ports — USB (s): 4x USB 2.0 (Front); 4x USB 5Gbps Type A (Front); 11x USB 10Gbps Type A (Rear); 2x USB 10Gbps Type C (Rear); 1x USB 20Gbps Type C (Front); * To achieve USB PD 60W fast charging for JUSBC1, the PD_PWR1 connector needs to be connected to the power supply unit.
Highlights — Graphics Output: 1x HDMI, 2x Type-C DisplayPort
Connector & Ports — LAN Port (s): 1x Marvell® AQC113CS 10Gbps LAN
Basic Information — Supported CPU: Supports Intel Core Ultra Processors (Series 2)
Connector & Ports — Display Port (s): 2x Type-C DisplayPort; Thundebolt 4 ports supporting DisplayPort 1.4 with HBR3 over USB Type-C, with a maximum resolution of 8K@60Hz*
Connector & Ports — Supported Storage: 5x M.2; M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices; M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices; M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices; M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280 devices; M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260 devices; 4x SATA 6G; ; * M2_4 default from chipset, can support PCIe 5.0 x4 (From CPU) by manual BIOS adjustment.; ** Please refer to the manual for M.2 SSD heatsink restrictions.
Connector & Ports — Internal I/O Ports: 1x Thunderbolt5 card connector(JTBT5, support RTD3); 1x Power Connector(ATX_PWR); 2x Power Connector(CPU_PWR); 1x Power Connector(PCIE_PWR 8pin); 1x Front Type-C Quick Charge Connector(PD_PWR1); 1x CPU Fan; 2x Combo Fan (Pump_Sys Fan); 5x System Fan; 1x EZ Conn-header (JAF_2); 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Water Flow connector; 1x Slow Mode Booting Jumper(JSLOW); 1x Front Audio (JAUD); 2x Thermal Sensor connectors(T_SEN); 1x Tuning Controller connector(JDASH); 3x Addressable V2 RGB LED connector (JARGB_V2); 1x RGB LED connector(JRGB); 1x TPM pin header(Support TPM 2.0); V-check point; 4x USB 2.0 ports; 4x USB 5Gbps Type A ports; 1x USB 20Gbps Type C ports
Warranty Information — Manufacturing Warranty: 3 year warranty
Connector & Ports — Wireless Communication module: Intel Killer BE1750x Wi-Fi 7; The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps; Supports 802.11 a/ b/ g/ n/ ac/ ax/ be; ; Supports Bluetooth 5.4**, MLO, 4KQAM;
Connector & Ports — TPM (Trusted Platform Module ): 1x TPM pin header(Support TPM 2.0)

Compare with similar products

	This itemMSI MEG Z890 ACE LGA 1851 ATX Motherboard	AsusAsus ROG CROSSHAIR X870E HERO AMD AM5 ATX Motherboard	AsusASUS ROG MAXIMUS Z890 HERO LGA 1851 WiFi ATX Gaming Motherboard	AsusASUS ROG MAXIMUS Z890 HERO BTF LGA1851 ATX Motherboard
Price	৳103,900	৳103,500	৳103,500	৳106,500
Availability	Out of stock	In stock	Out of stock	In stock
Brand	MSI	Asus	Asus	Asus
M.2 slots	5	5	6	6
RAM type	Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 9200+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 4800+ MT/s; • 2DPC 2R Max speed up to 4800+ MT/s	Supports up to; 8200+MT/s(OC) with Ryzen™ 9000 Series Processors,; 8600+MT/s(OC) with Ryzen™ 8000 Series Processors,; 8000+MT/s(OC) with Ryzen™ 7000 Series Processors,; ECC and Non-ECC, Un-buffered Memory*; Dual channel memory architecture ; Supports AMD Extended Profiles for Overclocking (EXPO™); NitroPath DRAM Technology; ASUS Enhanced Memory Profile (AEMP)	Support up to 9200+MT/s (OC), Non-ECC, Un-buffered, Clocked Unbuffered DIMM (CUDIMM)*; Dual channel memory architecture	Support up to 9200+MT/s (OC), Non-ECC, Un-buffered, Clocked Unbuffered DIMM (CUDIMM)*; Dual channel memory architecture; Supports Intel® Extreme Memory Profile (XMP) memory module; Supports DIMM Flex; NitroPath DRAM Technology; DIMM FIT; ASUS Enhanced Memory Profile III (AEMP III)
Form factor	ATX (243.84mmx304.8mm)	ATX Form Factor; 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )	ATX Form Factor ; 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )	ATX Form Factor; 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Chipset	INTEL Z890	AMD X870E	Intel Z890 Chipset	Intel Z890 Chipset
