MSI MPG B650I EDGE WIFI DDR5 AMD AM5 Mini-ITX Motherboard
Model: MPG B650I EDGE WIFIItem #: msi-mpg-b650i-edge-wifi-motherboard
৳33,500
Out of stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- AMD B650 Chipset
- Memory Support DDR5 6600+(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz; Max. overclocking frequency:; • 1DPC 1R Max. speed up to 6600+ MHz; • 1DPC 2R Max. speed up to 6000+ MHz; ; Support Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports AMD EXPO RAM type
- Mini-ITX; 170mmx170mm Form factor
Overview
The MSI MPG B650I EDGE WIFI Motherboard supports AMD's Ryzen 8000 & 7000-series processors with up to 16 Zen 4 cores as well as two dual-channel DDR5 memory, with a Maximum Memory Capacity of up to 64GB and a bus speed of up to 6600+(OC) MHz. It comes with four SATA and two M.2 interfaces that allow you to create an array of storage drives for your games, media, and other important applications. It is equipped with a single PCIe 4.0 x16 slot. The back panel provides you with ample connectivity options, giving you two USB-A 3.2 Gen 1 and three USB-A 3.2 Gen 2 ports with data transfer speeds up to 5 and 10 Gb/s, respectfully, suitable for a wide range of peripherals such as capture cards, microphones, and more. The motherboard is made of a 10-layer PCB made of 2oz thickened copper and server-grade level material. The rear I/O panel now offers easy ways of directly entering the safe boot, a one-click toggle for all RGB lights, and directly activating Turbo mode. The MSI MPG B650I EDGE WIFI offers you ample connectivity options, giving you seven USB-A 3.2 Gen 1 and 2 ports with data transfer speeds up to 5 and 10 Gb/s, respectfully, suitable for a wide range of peripherals such as capture cards, microphones, and more. A single USB-C 3.2 Gen 2x2 port offers up to 20 Gb/s speeds, suitable for audio arrays. The MAG B650 series motherboards offer a wide variety of options to connect and boost your USB devices, offering never before seen USB speeds up to 20Gb/s when connecting the Rear USB Type-C. The MSI MPG B650I EDGE WIFI comes with 3 years of warranty.
Specifications
- Chipset
- AMD B650
- RAM type
- Memory Support DDR5 6600+(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz; Max. overclocking frequency:; • 1DPC 1R Max. speed up to 6600+ MHz; • 1DPC 2R Max. speed up to 6000+ MHz; ; Support Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports AMD EXPO
- Form factor
- Mini-ITX; 170mmx170mm
- Memory — Type
- DDR5
- Memory — Slots
- 2 DIMMs
- Highlights — Model
- MPG B650I EDGE WIFI
- Graphics — Graphics
- 1x HDMI; Support HDMI 2.1 FRL, maximum resolution of 4K 120Hz
- Expansion Slots — PCI
- 1x PCI-E x16 slot; PCI_E1 PCIe 4.0 supports up to x16 (From CPU)
Show all 24 specificationsShow fewer
- Highlights — Features
- 2.5G LAN and AMD Wi-Fi 6E Solution
- Memory — Maximum Memory
- 64GB
- Connector & Ports — HDMI
- 1x HDMI
- Connector & Ports — RAID
- Supports RAID 0 , RAID 1 and RAID 10 for SATA storage devices; Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
- Basic Information — Audio
- Realtek ALC4080 Codec; 7.1-Channel USB High Performance Audio; Supports up to 32-Bit/384 kHz playback on front panel
- Connector & Ports — Audio
- Audio Connectors
- Others — Special Features
- 4x EZ Debug LED
- Highlights — Supported RAM
- 2x DDR5, up to 6600+(OC) MHz
- Connector & Ports — USB (s)
- 2x USB 2.0 (Front); 2x USB 3.2 Gen1 Type A (Rear); 2x USB 3.2 Gen1 Type A (Front); 3x USB 3.2 Gen2 Type A (Rear); 1x USB 3.2 Gen2 Type C (Front); 1x USB 3.2 Gen2x2 Type C (Rear)
- Highlights — Graphics Output
- 1x HDMI
- Connector & Ports — LAN Port (s)
- Realtek RTL8125BG 2.5Gbps LAN
- Basic Information — Supported CPU
- Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors; Socket AM5
- Connector & Ports — Supported Storage
- 2x M.2 slot; M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices; M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices; 4x SATA 6G port
- Connector & Ports — Internal I/O Ports
- 1x Power Connector(ATX_PWR); 1x Power Connector(CPU_PWR); 1x CPU Fan; 1x Pump Fan; 1x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Addressable V2 RGB LED connector (JARGB_V2); 2x USB 2.0; 2x USB 3.2 Gen1 Type A; 1x USB 3.2 Gen2 Type C
- Warranty Information — Manufacturing Warranty
- 3 Years
- Connector & Ports — Wireless Communication module
- AMD Wi-Fi 6E; The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX; Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands; Supports 802.11 a/ b/ g/ n/ ac/ ax; ; Supports Bluetooth 5.2
Compare with similar products
 This itemMSI MPG B650I EDGE WIFI DDR5 AMD AM5 Mini-ITX Motherboard |  GIGABYTEGIGABYTE B860 EAGLE WIFI6E LGA1851 ATX Motherboard |  GIGABYTEGIGABYTE B650 AORUS ELITE AX DDR5 AMD AM5 ATX Motherboard |  MSIMSI MAG B860 TOMAHAWK WIFI LGA 1851 ATX Motherboard | |
|---|---|---|---|---|
| Price | ৳33,500 | ৳33,400 | ৳33,500 | ৳33,600 |
| Availability | Out of stock | In stock | Out of stock | Out of stock |
| Brand | MSI | GIGABYTE | GIGABYTE | MSI |
| RAM type | Memory Support DDR5 6600+(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz; Max. overclocking frequency:; • 1DPC 1R Max. speed up to 6600+ MHz; • 1DPC 2R Max. speed up to 6000+ MHz; ; Support Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports AMD EXPO | Support for DDR5 9066(O.C)/8800(O.C) /8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) /6400/5600 MT/s memory modules | 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules; Dual channel memory architecture; Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules | Memory Support 9200 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 9200+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 6400+ MT/s; • 2DPC 2R Max speed up to 5600+ MT/s; Supports Intel® POR Speed and JEDEC Speed; Supports Memory Overclocking and Intel® XMP 3.0; Supports Dual-Controller Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM |
| Form factor | Mini-ITX; 170mmx170mm | ATX Form Factor; 30.5cm x 24.4cm | ATX Form Factor; 30.5cm x 24.4cm | ATX; 243.84mmx304.8mm |
| Chipset | AMD B650 | Intel B860 Express Chipset | AMD B650 | INTEL B860 |
| M.2 slots | — | 1 | — | 3 |
