MSI PRO B760M-G DDR4 mATX Motherboard
Model: PRO B760M-G DDR4Item #: msi-pro-b760m-g-ddr4-motherboard
৳13,800
Out of stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- INTEL B760 Chipset
- Memory Support 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC); Max. overclocking frequency:; • 1DPC 1R Max speed up to 4800+ MHz; • 1DPC 2R Max speed up to 4600+ MHz; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Intel® Extreme Memory Profile (XMP) RAM type
- mATX; 220mmx243.84mm Form factor
Overview
The MSI PRO B760M-G DDR4 mATX Motherboard is a high-performance motherboard that supports a broad selection of Intel CPUs, making it an appealing option for both casual and professional users. This motherboard supports Intel Core 14th, 13th, and 12th Generation CPUs, as well as Pentium Gold and Celeron processors. It makes use of the LGA 1700 socket for a variety of CPU choices. The motherboard supports DDR4 memory, with a dual-channel configuration and a clock speed of 4800+MHz (when overclocked). This guarantees that multitasking and data management go smoothly. The Core Boost technology, with its superior architecture and digital power design, assures that the motherboard can handle more CPU cores, leading to higher overall performance. This is particularly useful for demanding applications. Memory Boost technology is used to transmit clean and reliable data signals, guaranteeing excellent performance, stability, and compatibility with the memory modules installed. PCIe 4.0 compatibility is included, as well as Lightning Gen4 x4 M.2 slots with M.2 Shield Frozr. This implies you may use high-speed storage devices and other PCIe peripherals to achieve lightning-fast data transfer and loading times. The addition of a 2.5 Gigabit LAN connector upgrades the network solution for professional and multimedia applications. This assures a safe, reliable, and fast network connection, lowering latency and enhancing streaming performance while online gaming. The motherboard has Audio Boost technology, which provides studio-level sound quality for an immersive gaming experience. This function is especially useful for gamers who value crystal-clear audio during gaming sessions. Steel Armor is included on the motherboard to protect VGA cards from bending and electromagnetic interference (EMI). This not only improves the performance and stability of your graphics card but also assures the motherboard's general robustness and endurance.
Buy MSI PRO B760M-G mATX Motherboard Shop in BD
Specifications
- Chipset
- INTEL B760
- RAM type
- Memory Support 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC); Max. overclocking frequency:; • 1DPC 1R Max speed up to 4800+ MHz; • 1DPC 2R Max speed up to 4600+ MHz; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Intel® Extreme Memory Profile (XMP)
- Form factor
- mATX; 220mmx243.84mm
- Memory — Type
- DDR4
- Memory — Slots
- 2
- Highlights — Model
- PRO B760M-G DDR4
- Graphics — Graphics
- 1x HDMI; Support HDMI 2.1 with HDR, maximum resolution of 4K 60Hz; 1x DisplayPort; Support DP 1.4, maximum resolution of 4K 60Hz*; 1x VGA; Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz
- Expansion Slots — PCI
- 1x PCI-E x16 slot; 1x PCI-E x1 slot; PCI_E1 Gen PCIe 4.0 supports up to (From CPU); PCI_E2 Gen PCIe 4.0 supports up to (From Chipset)
Show all 25 specificationsShow fewer
- Highlights — Features
- 2x M.2 slot, Realtek RTL8125B 2.5Gbps LAN
- Memory — Maximum Memory
- 64GB
- Connector & Ports — HDMI
- 1x HDMI
- Connector & Ports — RAID
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Basic Information — Audio
- Realtek ALC897 Codec; 7.1-Channel High-Definition Audio
- Others — Special Features
- 4x EZ Debug LED
- Highlights — Supported RAM
- 2x DDR4, Max 64GB 4800(OC)
- Connector & Ports — USB (s)
- 2x USB 2.0 (Rear); 4x USB 2.0 (Front); 4x USB 3.2 Gen1 Type A (Rear); 2x USB 3.2 Gen1 Type A (Front)
- Connector & Ports — VGA (s)
- 1x VGA
- Highlights — Graphics Output
- 1x HDMI, 1x DP, 1x VGA
- Connector & Ports — LAN Port (s)
- Realtek RTL8125B 2.5Gbps LAN
- Basic Information — Supported CPU
- Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold and Celeron Processors; LGA 1700
- Connector & Ports — Display Port (s)
- 1x DisplayPort
- Connector & Ports — Supported Storage
- 2x M.2; M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices; M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices; 4x SATA 6G
- Connector & Ports — Internal I/O Ports
- 1x Power Connector(ATX_PWR); 1x Power Connector(CPU_PWR); 1x CPU Fan; 2x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 2x Addressable V2 RGB LED connector (JARGB_V2); 1x RGB LED connector(JRGB); 4x USB 2.0 ports; 2x USB 3.2 Gen1 Type A ports
- Warranty Information — Manufacturing Warranty
- 3 years
- Connector & Ports — TPM (Trusted Platform Module )
- 1x TPM pin header(Support TPM 2.0);
Compare with similar products
 This itemMSI PRO B760M-G DDR4 mATX Motherboard |  AsusAsus PRIME B650M-F AM5 mATX Motherboard |  ASRockASRock B760M-HDV/M.2 DDR5 Micro ATX Motherboard |  GIGABYTEGIGABYTE A620M S2H AMD AM5 Micro-ATX Motherboard | |
|---|---|---|---|---|
| Price | ৳13,800 | ৳13,800 | ৳13,800 | ৳13,800 |
| Availability | Out of stock | In stock | Out of stock | Out of stock |
| Brand | MSI | Asus | ASRock | GIGABYTE |
| RAM type | Memory Support 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC); Max. overclocking frequency:; • 1DPC 1R Max speed up to 4800+ MHz; • 1DPC 2R Max speed up to 4600+ MHz; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Intel® Extreme Memory Profile (XMP) | 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 Non-ECC, Un-buffered Memory; Dual channel memory architecture; Supports AMD Extended Profiles for Overclocking (EXPO) | - Dual Channel DDR5 Memory Technology; - 2 x DDR5 DIMM Slots; - Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC)*; - Supports Intel Extreme Memory Profile (XMP) 3.0 | Support for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules; Dual channel memory architecture; Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules |
| Form factor | mATX; 220mmx243.84mm | micro-ATX Form Factor; 8.9 inch x 8.6 inch (22.6 cm x 21.8 cm) | - Micro ATX Form Factor: 9.6-in x 7.9-in, 24.4 cm x 20.1 cm | Micro ATX Form Factor; 23.0cm x 22.5cm; |
| Chipset | INTEL B760 | AMD B650 Chipset | Intel B760 | AMD A620 |
