XENTHRA XN-H311M-VH-PRO Intel 9th Gen mATX Motherboard
Model: XN-H311M-VH-PROItem #: xenthra-xn-h311m-vh-pro-motherboard
৳6,550৳6,800Save 4%
In stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- Intel H110 Express Chipset
- 1 M.2 slots
- Up to DDR4 2666 MHz RAM type
- Micro-ATX (180 mm x 216 mm) Form factor
Overview
XENTHRA XN‑H311M‑VH‑PRO Intel 9th Gen mATX Motherboard is a dependable platform built to support Intel’s 6th, 7th, 8th, and 9th Generation Core, Pentium, and Celeron processors. Powered by the Intel H110 Express Chipset and designed with the LGA 1151 socket, this XENTHRA XN‑H311M‑VH‑PRO Motherboard provides a strong foundation for versatile desktop builds. Its compact micro‑ATX form factor (180mm x 216mm) makes it suitable for space‑efficient setups while still offering essential features for modern computing.
The XENTHRA 9th Gen Motherboard supports DDR4 memory with two dual‑channel slots, allowing up to 64GB of RAM at speeds up to DDR4‑2666 MHz. This ensures smooth multitasking and reliable performance for demanding applications. Expansion options include one PCIe 3.0 x16 slot for graphics cards and one PCIe 2.0 x1 slot for add‑on components, giving flexibility for upgrades.
Connectivity is comprehensive, with HDMI and VGA outputs, two USB 3.0 ports, four USB 2.0 ports, and a Realtek Gigabit LAN port for fast networking. Storage support includes one M.2 slot with NVMe PCIe 2.0 x4 compatibility and four SATA 3.0 ports, offering both modern SSD performance and traditional HDD capacity. This makes the XENTHRA H311M Motherboard future‑ready for storage expansion.
Additional features include three audio jacks for Line Out, Mic In, and Line In, internal headers for CPU and system fans, diagnostic card support, TPM 2.0 header for trusted security, and a PS/2 combo port for legacy peripherals. With its balance of performance, expandability, and everyday usability, the XENTHRA Intel Motherboard is a practical choice for users upgrading or building reliable desktop systems.
Specifications
- Chipset
- Intel H110 Express Chipset
- M.2 slots
- 1
- RAM type
- Up to DDR4 2666 MHz
- Form factor
- Micro-ATX (180 mm x 216 mm)
- Memory — Type
- DDR4
- Memory — Slots
- 2 x Dual-Channel Memory
- Highlights — Model
- XN-H311M-VH-PRO
- Expansion Slots — PCI
- 1x PCIe 3.0 x16 Slot (PCIe 3.0 x16 signal); 1x PCIe 2.0 x1 Slot (PCIe 2.0 x1 signal)
Show all 23 specificationsShow fewer
- Highlights — Features
- 1x RJ45 Gigabit LAN, 1x M.2 (PCIe 2.0 x4)
- Memory — Maximum Memory
- Up to 64 GB (Supports 2x 32GB or 16GB per single slot)
- Connector & Ports — HDMI
- 1x HDMI
- Basic Information — Audio
- 3x Audio Jacks (Line Out, Mic In, Line In)
- Connector & Ports — Audio
- 3x Audio Jacks (Line Out, Mic In, Line In)
- Highlights — Supported RAM
- 2x DDR4 DIMM Up to 64 GB 2666Mhz
- Connector & Ports — USB (s)
- 1x PS/2 Keyboard/Mouse Combo Port; 2x USB 3.0 Ports, 4x USB 2.0 Ports
- Connector & Ports — VGA (s)
- 1x VGA (D-Sub)
- Highlights — Graphics Output
- 1 x VGA, 1 x HDMI
- Connector & Ports — LAN Port (s)
- 1x RJ45 Port (Realtek Gigabit LAN)
- Basic Information — Supported CPU
- Supports Intel 6th, 7th, 8th & 9th Gen Core / Pentium / Celeron Processors
- Connector & Ports — Supported Storage
- 1x M.2 Slot (Supports NVMe PCIe 2.0 x4 mode); 4x SATA 3.0 (6 Gbps) Ports
- Connector & Ports — Internal I/O Ports
- 1x COM Header (Supports RS232 mode); 1x 4-Pin CPU Fan Connector, 1x 4-Pin SYS Fan, 1x 3-Pin SYS Fan; 2x 5-Pin Diagnostic Card Header, 1x JBAT Jumper Cap
- Warranty Information — Manufacturing Warranty
- 03 years
- Connector & Ports — TPM (Trusted Platform Module )
- 1x TPM 2.0 Header
