ASUS PRIME H610I-PLUS DDR5 Mini ITX Motherboard
Model: PRIME H610I-PLUSItem #: asus-prime-h610i-plus-motherboard
৳16,900৳17,500Save 3%
In stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- Intel H610 Chipset
- 1 M.2 slots
- 5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) RAM type
- Mini ITX Form Factor; 6.7 inch x 6.7 inch ( 17.02 cm x 17.02 cm )
Overview
The ASUS PRIME H610I-PLUS DDR5 is a compact and feature-rich Mini ITX motherboard designed for users seeking high performance in a small form factor. Based on the Intel H610 chipset, it supports the latest DDR5 memory technology, offering speeds up to 5600 MHz. Compatible with 14th, 13th, and 12th Gen Intel Core processors through its LGA 1700 socket, it provides a wide range of CPU options for various performance needs. The motherboard boasts an enhanced power solution with 5+1+1 DrMOS power stages, ensuring stable and efficient power delivery to the CPU and other critical components. Cooling is comprehensively managed through VRM and PCH heatsinks, complemented by Fan Xpert, ensuring the system stays cool under load. For connectivity, the motherboard includes a 32Gbps M.2 slot for high-speed storage solutions, Intel 1 Gb Ethernet for reliable network connectivity, and multiple USB 3.2 Gen 1 ports for fast data transfer and peripheral connectivity. Display options are versatile, with support for DisplayPort, HDMI, and D-Sub, catering to various monitor setups. Storage needs are met with SATA 6 Gbps ports, and additional peripheral connectivity is facilitated through a COM header and Mono-out header with Amp IC. The ASUS PRIME H610I-PLUS DDR5 also incorporates 5X Protection III, which includes multiple hardware safeguards to ensure all-around protection and durability, enhancing the longevity and reliability of the motherboard. This well-rounded motherboard combines cutting-edge technology with robust features, making it an excellent choice for building a compact yet powerful PC.
Specifications
- Chipset
- Intel H610 Chipset
- M.2 slots
- 1
- RAM type
- 5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP)
- Form factor
- Mini ITX Form Factor; 6.7 inch x 6.7 inch ( 17.02 cm x 17.02 cm )
- Memory — Type
- DDR5
- Memory — Slots
- 2x DIMM
- Highlights — Model
- PRIME H610I-PLUS
- Graphics — Graphics
- Supports max. 4K@60Hz as specified in DisplayPort 1.4.; Supports 4K@60Hz as specified in HDMI 2.1
Show all 27 specificationsShow fewer
- Expansion Slots — PCI
- Intel Core Processors (14th & 13th & 12th Gen); 1 x PCIe 4.0 x16 slot
- Highlights — Features
- 1 x Realtek 1Gb Ethernet
- Memory — Maximum Memory
- Max. 96GB
- Basic Information — BIOS
- 128 Mb Flash ROM, UEFI AMI BIOS
- Connector & Ports — HDMI
- 1 x HDMI port
- Basic Information — Audio
- Realtek 7.1 Surround Sound High Definition Audio CODEC; - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; - Supports up to 24-Bit/192 kHz playback; Audio Features; - Audio Shielding; - Dedicated audio PCB layers
- Connector & Ports — Audio
- 3x Audio jacks
- Others — Special Features
- ASUS 5X PROTECTION III; - DIGI+ VRM; - LANGuard; - Overvoltage Protection; - SafeSlot Core; - Stainless-Steel Back I/O; ASUS Q-Design; - Q-DIMM; - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]); - Q-Slot; ASUS Thermal Solution; - Aluminum heatsink design
- Highlights — Supported RAM
- 2x DDR4, Max 64GB 3200
- Connector & Ports — USB (s)
- Rear USB (Total 4 ports); 2 x USB 3.2 Gen 1 (5G) ports (2 x Type-A); 2 x USB 2.0 ports (2 x Type-A); Front USB (Total 4 ports); 1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports; 1 x USB 2.0 header supports 2 additional USB 2.0 ports
- Connector & Ports — VGA (s)
- 1 x VGA port
- Highlights — Graphics Output
- 1x HDMI port, 1x DisplayPort, 1 x D-Sub
- Connector & Ports — LAN Port (s)
- 1 x Intel 1Gb Ethernet port
- Basic Information — Supported CPU
- Intel Socket LGA1700 for Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium Gold and Celeron Processors; Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
- Connector & Ports — Display Port (s)
- 1 x DisplayPort
- Connector & Ports — Supported Storage
- Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports; Intel H610 Chipset; M.2 slot (Key M), type 2260/2280 (supports PCIe 3.0 x4 mode); 4 x SATA 6Gb/s ports
- Connector & Ports — Internal I/O Ports
- Internal I/O Connectors; Fan and Cooling-related; 1 x 4-pin CPU Fan header; 1 x 4-pin CPU OPT Fan header; 1 x 4-pin Chassis Fan header; Power related; 1 x 24-pin Main Power connector; 1 x 8-pin +12V Power connector; Storage related; 1 x M.2 slot (Key M); 4 x SATA 6Gb/s ports; USB; 1 x USB 3.2 Gen 1 (5G) header supports additional 2 USB 3.2 Gen 1 ports; 1 x USB 2.0 header supports 2 additional USB 2.0 ports; Miscellaneous; 1 x Clear CMOS header; 1 x COM Port header; 1 x Front Panel Audio header (AAFP); 1 x Mono-out header(with Amp IC); 1 x SMBUS header; 1 x Speaker header; 1 x SPI TPM header (14-1pin); 1 x 10-1 pin System Panel header
- Warranty Information — Manufacturing Warranty
- 3 years warranty
- Connector & Ports — Wireless Communication module
- M.2 slot only (Key E, CNVi & PCIe); *Wi-Fi module is sold separately.
Compare with similar products
 This itemASUS PRIME H610I-PLUS DDR5 Mini ITX Motherboard |  MSIMSI PRO B650M-P DDR5 AMD AM5 mATX Motherboard |  AsusASUS PRO B760M-C-CSM Micro-ATX Motherboard |  GIGABYTEGIGABYTE B650M GAMING WIFI mATX AM5 Motherboard | |
|---|---|---|---|---|
| Price | ৳16,900 | ৳16,900 | ৳16,900 | ৳16,900 |
| Availability | In stock | In stock | In stock | In stock |
| Brand | Asus | MSI | Asus | GIGABYTE |
| M.2 slots | 1 | — | — | 1 |
| RAM type | 5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) | Memory Support DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz; Max. overclocking frequency:; • 1DPC 1R Max speed up to 7200+ MHz; • 1DPC 2R Max speed up to 6000+ MHz; • 2DPC 1R Max speed up to 6000+ MHz; • 2DPC 2R Max speed up to 5400+ MHz; ; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports AMD EXPO | DDR5 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 Non-ECC, Un-buffered Memory*; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP); Optimem II | Support for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules; Dual channel memory architecture; Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme; Memory Profile (XMP) memory modules |
| Form factor | Mini ITX Form Factor; 6.7 inch x 6.7 inch ( 17.02 cm x 17.02 cm ) | mATX; 243.84mmx243.84mm | mATX Form Factor; 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm) | Micro ATX Form Factor; 24.0cm x 22.5cm |
| Chipset | Intel H610 Chipset | AMD B650 | Intel B760 Chipset | AMD B650 |
