ASUS Pro Q570M-C/CSM LGA1200 mATX Motherboard

Name: ASUS Pro Q570M-C/CSM LGA1200 mATX Motherboard
Brand: Asus
Price: 11800 BDT
Availability: InStock

Model: Pro Q570M-C/CSMItem #: asus-pro-q570m-c-csm-motherboard

৳11,800~~৳12,800~~Save 8%

In stockverified 22 Sept 2026

Ordering is paused

We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.

Delivery

Inside Dhaka: ৳60 · 1–2 days
Outside Dhaka: ৳120 · 2–4 days

Sold by Micro

Key highlights

Intel Q570 Chipset
11 M.2 slots
DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP); Optimem; 10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.; 11th Gen Intel processors support 2933/2800/2666/2400/2133 natively. RAM type
mATX Form Factor

Overview

The ASUS Pro Q570M-C/CSM LGA1200 mATX Motherboard is a professional-grade platform built for stability, performance, and long-term reliability. Designed for 11th and 10th Gen Intel Core, Pentium Gold, and Celeron processors, this ASUS Intel Motherboard offers robust compatibility through the LGA1200 socket and supports Intel Turbo Boost and Turbo Boost Max Technology 3.0 for enhanced processing power. With dual-channel DDR4 memory support up to 128GB and frequencies up to 3200MHz (OC), the ASUS Pro Q570M-C/CSM Motherboard ensures smooth multitasking and dependable system responsiveness for business or technical applications. Optimem technology improves signal integrity and stability, while PCIe 4.0 delivers next-level bandwidth for graphics and expansion cards. Storage options on the ASUS Pro Q570M-C/CSM LGA1200 mATX Motherboard include dual M.2 slots supporting PCIe 4.0/3.0 and six SATA 6Gb/s ports for SSDs and HDDs. The motherboard also supports Intel Optane Memory, RAID configurations, and high-speed data transfers for faster boot and load times. Connectivity is equally impressive, with four USB 3.2 Gen 2 ports, a USB 3.2 Gen 1 Type-C front header, multiple USB 2.0 headers, and Intel 1Gb Ethernet for reliable wired networking. Audio performance is powered by the Realtek ALC897 codec, offering 7.1-channel high-definition surround sound for immersive experiences. The ASUS Pro Q570M-C/CSM Motherboard is engineered with business reliability in mind, featuring moisture-resistant coating, overcurrent protection, and ASUS Self-Recovering BIOS for automatic system recovery. It includes an event log for detailed system tracking and a COM debug header for efficient troubleshooting. IT administrators benefit from ASUS Control Center Express (ACCE), enabling streamlined remote management and monitoring. With TPM 2.0, robust security, and 24/7 reliability, the ASUS Pro Q570M-C/CSM Motherboard stands out as a trusted choice for professionals seeking a durable, secure, and high-performance ASUS Intel Motherboard built to handle demanding business and industrial computing needs.

Specifications

Chipset: Intel Q570 Chipset
M.2 slots: 11
RAM type: DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP); Optimem; 10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.; 11th Gen Intel processors support 2933/2800/2666/2400/2133 natively.
Form factor: mATX Form Factor
Memory — Type: DDR4
Memory — Slots: 4x DIMM
Highlights — Model: Pro Q570M-C/CSM
Graphics — Graphics: Graphics specifications may vary between CPU types.; Intel 11th & 10th processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz.; Only Intel 11th processors support HDMI 2.0 with max. resolution of 4K@60Hz, others will only support HDMI 1.4 with max. resolution of 4K@30Hz

Show all 27 specifications

Expansion Slots — PCI: Intel 11th & 10th Gen Processors; 1 x PCIe 4.0/3.0 x16 slot; Intel 11th processors support PCIe 4.0 x16 mode; Intel 10th processors support PCIe 3.0 x16 mode; Intel Q570 Chipset; 2 x PCIe 3.0 x1 slots
Highlights — Features: 1x M.2, Intel I219-LM 1Gb Ethernet
Memory — Maximum Memory: Max. 128GB
Basic Information — BIOS: 128+64 Mb Flash ROM
Connector & Ports — HDMI: 1x HDMI
Basic Information — Audio: Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC; Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; Supports up to 24-Bit/192 kHz playback
Connector & Ports — Audio: Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC; Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; Supports up to 24-Bit/192 kHz playback; A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Others — Bundled Software: ASUS Exclusive Software; IT Management software supported; - ASUS Control Center Express(ACCE)
Others — Special Features: ASUS EZ DIY; - Box Headers; Bespoke Motherboard Design & Business Focused Features; - ASUS Self Recovering BIOS; - ASUS Event Log; - ASUS Commercial BIOS kit; - Anti-Moisture; - 24/7 Reliability; - Overcurrent Protection
Highlights — Supported RAM: 4x DDR4, Max 128GB 3200(O.C.)
Connector & Ports — USB (s): 4 x USB 3.2 Gen 2 ports (4 x Type-A); 2x USB 2.0 ports (2 x Type-A)
Highlights — Graphics Output: 1x DisplayPort 1.4, 1x HDMI 2.0
Connector & Ports — LAN Port (s): 1 x Intel I219-LM 1Gb Ethernet
Basic Information — Supported CPU: Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors; Supports Intel 14 nm CPU; Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0; Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.
Connector & Ports — Display Port (s): 2 x DisplayPort
Connector & Ports — Supported Storage: Intel 11th & 10th Gen Processors; M.2_1 slot (Key M), type 2242/2260/2280; Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs; Intel Q570 Chipset; M.2_2 slot (Key M), type 2242/2260/2280(supports PCIe 3.0 x4 & SATA modes); 6 x SATA 6Gb/s ports; When a device in SATA mode is installed on the M.2_2 socket, SATA6G_2 port cannot be used.; RAID function for PCIe mode SSD in Intel Rapid Storage Technology is available with either 1. Intel SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.; To enable Intel Optane Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel® Rapid Storage Technology.
Connector & Ports — Internal I/O Ports: Fan and cooling related; 1 x 4-pin CPU Fan header; 2 x 4-pin Chassis Fan headers; Power related; 1 x 24-pin Main Power connector; 1 x 8-pin +12V Power connector; Storage related; 2 x M.2 slots (Key M); 6 x SATA 6Gb/s ports; USB; 1 x USB 3.2 Gen 1 Front Panel connector (suppports USB Type-C); 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports; 2 x USB 2.0 headers support additional 4 USB 2.0 ports; Miscellaneous; 1 x Clear CMOS header; 1 x Chassis Intrude header; 2 x COM Port headers; 1 x Front Panel Audio header (AAFP); 1 x COM debug header; 1 x DIS ME jumper; 1 x LPT header; 1 x Mono-out header(with Amp IC); 1 x M.2 slot (Key E); 1 x SMBUS header; 1 x Speaker header; 1 x 10-1 System Panel header; Back Panel I/O Ports; 4 x USB 3.2 Gen 2 ports (4 x Type-A); 2x USB 2.0 ports (2 x Type-A); 2 x DisplayPort; 1 x HDMITM; 3 x Audio jacks; 1 x Intel® I219-LM 1Gb Ethernet; 1 x PS/2 keyboard (purple) port; 1 x PS/2 mouse (green) port
Warranty Information — Manufacturing Warranty: 3 years
Connector & Ports — TPM (Trusted Platform Module ): TPM 2.0 IC onboard
