ASUS Z790-AYW OC WIFI LGA1700 ATX Motherboard
Model: Z790-AYW OC WIFIItem #: asus-z790-ayw-oc-wifi-motherboard
৳39,500৳43,290Save 9%
In stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- Intel Z790 Chipset
- 3 M.2 slots
- DDR5 8200+(OC) 8000(OC) /7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800; Non-ECC, Un-buffered Memory*; Dual channel memory architecture; Supports Intel® Extreme Memory Profile (XMP) memory module; OptiMem II; * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration RAM type
- ATX Form Factor; 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Overview
The ASUS Z790-AYW OC WIFI LGA1700 ATX Motherboard is built for high-performance computing. Powered by the Intel Z790 chipset, it supports Intel Core 14th, 13th, and 12th Gen processors, along with Pentium Gold and Celeron CPUs. With Intel Turbo Boost Technology 2.0 and 3.0, this ASUS Z790 Motherboard ensures fast speeds and reliable performance for gaming, content creation, and professional workloads.
DDR5 Memory Support
This ASUS Z790 ATX Motherboard supports DDR5 memory with speeds up to 8200+(OC) and dual-channel architecture. With OptiMem II technology and Intel XMP profiles, it delivers stable overclocking and reduced latency. The board supports up to 96GB of DDR5 memory, making it ideal for demanding applications and multitasking setups.
Expansion and Storage
The ASUS Z790-AYW OC WIFI Motherboard offers multiple PCIe 4.0 slots for graphics and expansion cards. Storage options include 3x M.2 slots with heatsinks and 4x SATA 6Gb/s ports, supporting Intel Rapid Storage Technology with RAID 0/1/5/10. ASUS Q-Design features like M.2 Q-Latch and Q-DIMM make installation simple and efficient.
Connectivity Options
Connectivity is extensive with HDMI 2.1 supporting 4K@60Hz, 8 rear USB ports including USB 10Gbps Type-A and Type-C, plus 9 front USB ports for expansion. Networking is powered by Realtek 2.5Gb Ethernet with ASUS LANGuard, Wi-Fi 6, and Bluetooth 5.3, ensuring fast and stable connections for gaming and professional use.
Audio and Cooling
The ASUS Z790 Motherboard features Realtek 7.1 Surround Sound High Definition Audio CODEC with premium capacitors and audio shielding for clear sound. Cooling is optimized with VRM heatsinks, M.2 heatsinks, multiple fan headers, and AI Cooling II via Fan Xpert 4. Extreme OC features like onboard start/reset buttons and clear CMOS support make it perfect for overclockers.
Durability and Features
ASUS 5X Protection III ensures durability with DIGI+ VRM, SafeSlot Core+, stainless-steel back I/O, and overvoltage protection. DIY-friendly features include BIOS FlashBack™, pre-mounted I/O shield, and Aura Sync RGB headers for customization. Bundled software such as Armoury Crate, AI Suite 3, and ASUS CPU-Z enhance system management and performance tuning.
ASUS Z790-AYW OC WIFI – Professional Choice
The ASUS Z790-AYW OC WIFI LGA1700 ATX Motherboard combines DDR5 support, advanced connectivity, robust cooling, and extreme overclocking features. Perfect for gamers, creators, and professionals, it delivers the performance and reliability expected from an ASUS Z790 Professional Motherboard.
Specifications
- Chipset
- Intel Z790 Chipset
- M.2 slots
- 3
- RAM type
- DDR5 8200+(OC) 8000(OC) /7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800; Non-ECC, Un-buffered Memory*; Dual channel memory architecture; Supports Intel® Extreme Memory Profile (XMP) memory module; OptiMem II; * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration
- Form factor
- ATX Form Factor; 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
- Memory — Type
- DDR5
- Memory — Slots
- 2 x DIMM slots
- Highlights — Model
- Z790-AYW OC WIFI
- Graphics — Graphics
- 1 x HDMI port; Supports 4K@60Hz as specified in HDMI 2.1
Show all 28 specificationsShow fewer
- Expansion Slots — PCI
- Intel® Core™ Processors (14th & 13th & 12th Gen)*; 1 x PCIe 4.0 x16 slot; Intel® Z790 Chipset; 2 x PCIe 4.0 x16 slots (support x4 mode); 2 x PCIe 4.0 x1 slots; * Please check the PCIe
- Highlights — Features
- Realtek 2.5Gb Ethernet and Wi-Fi 6
- Memory — Maximum Memory
- 96GB
- Basic Information — BIOS
- 192 (128+64) Mb Flash ROM, UEFI AMI BIOS
- Connector & Ports — HDMI
- 1 x HDMI 2.1
- Connector & Ports — RAID
- Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10.
- Basic Information — Audio
- Realtek 7.1 Surround Sound High Definition Audio CODEC
- Connector & Ports — Audio
- Realtek 7.1 Surround Sound High Definition Audio CODEC*; - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; - Supports up to 24-Bit/192 kHz playback"; Audio Features; - Audio Shielding; - Premium audio capacitors; - Dedicated audio PCB layers; * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
- Others — Bundled Software
- ASUS Exclusive Software; Armoury Crate; - Aura Sync; - Fan Xpert 4 (with AI Cooling II); - Power Saving; - Two-Way AI Noise Cancelation; AI Suite 3; -TurboV EVO; -PC Cleaner; -DIGI+ VRM; ASUS CPU-Z; Norton 360 Deluxe (60 Days Free Trial); WinRAR (40 Days Free Trial); MyASUS; UEFI BIOS; ASUS EZ DIY; - ASUS CrashFree BIOS 3; - ASUS EZ Flash 3; - ASUS UEFI BIOS EZ Mode
- Others — Special Features
- Extreme OC Kit; - Start button; ASUS 5X PROTECTION III; - DIGI+ VRM (- Digital power design with DrMOS); - LANGuard; - Overvoltage Protection; - SafeSlot Core+; - Stainless-Steel Back I/O; ASUS Q-Design; - M.2 Q-Latch; - Q-DIMM; - Q-Slot; - Q-Code; ASUS Thermal Solution; - M.2 heatsinks; - VRM heatsinks design; ASUS EZ DIY; - BIOS FlashBack™ button; - ProCool; - Pre-mounted I/O shield; Aura Sync; - Addressable Gen 2 headers
- Highlights — Supported RAM
- 2 x DIMM, Max. 96GB, DDR5 8200+(OC)
- Connector & Ports — USB (s)
- Rear USB (Total 8 ports); 2 x USB 10Gbps ports (1 x Type-A+1 x Type-C®); 2 x USB 5Gbps ports (2 x Type-A); 4 x USB 2.0 ports (4 x Type-A)*; Front USB (Total 9 ports); 1 x USB 10Gbps connector (supports USB Type-C®); 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports; 2 x USB 2.0 headers support 4 additional USB 2.0 ports*; * USB_E1 port, USB_E2 port and USB_E6 port share the bandwidth.; * USB_E3 port, USB_E4 port, USB_E7 port and USB_E8 port share the bandwidth.
- Highlights — Graphics Output
- 1 x HDMI
- Connector & Ports — LAN Port (s)
- 1 x Realtek 2.5Gb Ethernet; ASUS LANGuard
- Basic Information — Supported CPU
- Intel Socket LGA1700 for Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium Gold and Celeron Processors; Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
- Connector & Ports — Supported Storage
- 3 x M.2 slots (Key M); 4 x SATA 6Gb/s ports
- Connector & Ports — Internal I/O Ports
- Back Panel I/O Ports; 2 x USB 10Gbps ports (1 x Type-A+1 x Type-C®); 2 x USB 5Gbps ports (2 x Type-A); 4 x USB 2.0 ports (4 x Type-A); 1 x HDMI port; 1 x Wi-Fi Module; 1 x Realtek 2.5Gb Ethernet port; 3 x Audio jacks; 1 x BIOS FlashBack™ button; ; Internal I/O Connectors; Fan and Cooling related; 1 x 4-pin CPU Fan header; 1 x 4-pin CPU OPT Fan header; 1 x 4-pin AIO Pump header; 3 x 4-pin Chassis Fan headers; Power related; 1 x 24-pin Main Power connector; 1 x 8-pin +12V CPU Power connector; 1 x 4-pin +12V CPU Power connector; Storage related; 3 x M.2 slots (Key M); 4 x SATA 6Gb/s ports; USB; 1 x USB 10Gbps connector (supports USB Type-C®); 2 x USB 5Gbps headers support 4 additional USB 5Gbps ports; 2 x USB 2.0 headers support 4 additional USB 2.0 ports; Miscellaneous; 3 x Addressable Gen 2 headers; 1 x COM Port header; 1 x Front Panel Audio header (F_AUDIO); 1 x Start button; 1 x Clear CMOS button; 1 x Reset button; 1 x S/PDIF Out header; 1 x SPI TPM header (14-1pin); 1 x 20-5pin System Panel header; 1 x Thunderbolt (USB4®) Header
- Warranty Information — Manufacturing Warranty
- 3 years
- Connector & Ports — Wireless Communication module
- Wi-Fi 6 (802.11 ax); Supports 2.4/5GHz frequency band; Bluetooth v5.3
- Connector & Ports — TPM (Trusted Platform Module )
- 1 x SPI TPM header (14-1pin)
Compare with similar products
 This itemASUS Z790-AYW OC WIFI LGA1700 ATX Motherboard |  AsusAsus ROG STRIX B850-G GAMING WIFI mATX Motherboard |  MSIMSI X870 GAMING PLUS WIFI AM5 Motherboard |  AsusASUS Z790-AYW WIFI W II LGA1700 ATX Motherboard | |
|---|---|---|---|---|
| Price | ৳39,500 | ৳39,500 | ৳39,500 | ৳39,500 |
| Availability | In stock | In stock | Out of stock | Out of stock |
| Brand | Asus | Asus | MSI | Asus |
| M.2 slots | 3 | 4 | 3 | 3 |
| RAM type | DDR5 8200+(OC) 8000(OC) /7800(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800; Non-ECC, Un-buffered Memory*; Dual channel memory architecture; Supports Intel® Extreme Memory Profile (XMP) memory module; OptiMem II; * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration | Supports up to 8000+MT/s (OC) with Ryzen™ Supports up to 8000+MT/s(OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors; ECC and Non-ECC Un-buffered DIMM; Dual channel memory architecture ; Supports AMD Extended Profiles for Overclocking (EXPO™); ASUS Enhanced Memory Profile (AEMP) | Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s; Ryzen™ 9000 Series Processors max. overclocking frequency:; • 1DPC 1R Max speed up to 8200+ MT/s; • 1DPC 2R Max speed up to 6400+ MT/s; • 2DPC 1R Max speed up to 6400+ MT/s; • 2DPC 2R Max speed up to 4800+ MT/s; ; Supports AMD POR Speed and JEDEC Speed; Supports Memory Overclocking and AMD EXPOTM; Supports Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM, Clock Driver bypass mode only* | 8000+ OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory; Dual channel memory architecture; Supports Intel Extreme Memory Profile (XMP) memory module; OptiMem II |
| Form factor | ATX Form Factor; 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) | micro-ATX Form Factor ; 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm) | ATX; 243.84mmx304.8mm | ATX Form Factor; 12 inch x 9.6 inch (30.5 cm x 24.4 cm) |
| Chipset | Intel Z790 Chipset | AMD B850 | AMD X870 | Intel Z790 Chipset |
