Gigabyte B450M DS3H AM4 AMD Micro ATX Motherboard
Model: B450M DS3HItem #: gigabyte-b450m-ds3h-amd-motherboard
৳10,700৳10,800Save 1%
In stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- AMD B450 Chipset
- 1 M.2 slots
- Support for DDR4 3200(O.C.)/2933/2667/2400/2133 MHz memory modules; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules RAM type
- Micro ATX Form Factor; 24.4cm x 21.5cm
Overview
Gigabyte B450M DS3H AMD Micro ATX AM4 socket ryzen series CPU supported Dual Channel DDR4 maximum 64GB memory motherboard has the capability of Ultra-Fast PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode and 3 PCIe slots. Considering the graphics, it will support maximum resolution of 4096x2160@60 Hz for HDMI and 1920x1200@60 Hz for DVI-D ports for Multiple Display. This High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting motherboard has the facility of USB 3.1 Gen 1, RGB Fusion supports RGB LED Strips in 7-Colors and Realtek® Gigabit LAN with cFosSpeed Internet Accelerator Software.
Specifications
- Chipset
- AMD B450
- M.2 slots
- 1
- RAM type
- Support for DDR4 3200(O.C.)/2933/2667/2400/2133 MHz memory modules; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules
- Form factor
- Micro ATX Form Factor; 24.4cm x 21.5cm
- Memory — Type
- Dual Channel DDR4 Memory Technology
- Memory — Slots
- 4 x DIMM;
- Highlights — Model
- B450M DS3H
- Graphics — Graphics
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz; * The DVI-D port does not support D-Sub connection by adapter.; 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz(Note); * Support for HDMI 2.0 version and HDCP 2.2
Show all 22 specificationsShow fewer
- Highlights — Memory
- 4 x DDR4, Max 64 GB
- Expansion Slots — PCI
- 1 x PCI Express x16 slot, running at x16 (PCIEX16)(Note); * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.; (The PCIEX16 slot conforms to PCI Express 3.0 standard.); 1 x PCI Express x16 slot, running at x4 (PCIEX4); 1 x PCI Express x1 slot; (The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.)
- Memory — Maximum Memory
- 64 GB
- Basic Information — BIOS
- 1 x 128 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- Connector & Ports — HDMI
- 1 x HDMI port
- Connector & Ports — Audio
- Realtek® ALC887 codec; High Definition Audio; 2/4/5.1/7.1-channel; * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.; Support for S/PDIF Out
- Connector & Ports — USB (s)
- Chipset:; 2 x USB 3.1 Gen 1 ports available through the internal USB header; 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers); CPU:; 4 x USB 3.1 Gen 1 ports on the back panel
- Graphics — Max Shared Memory
- 2 GB
- Connector & Ports — LAN Port (s)
- Realtek® GbE LAN chip (10/100/1000 Mbit)
- Basic Information — Supported CPU
- AMD Ryzen™ 2nd Generation processors; AMD Ryzen™ with Radeon™ Vega Graphics processors; AMD Ryzen™ 1st Generation processors
- Connector & Ports — Supported Storage
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support); * Supports only M.2 SATA SSDs when using an AMD Athlon™ 200-series/ 7th Generation A-series or Athlon™ APU.; 4 x SATA 6Gb/s connectors; Support for RAID 0, RAID 1, and RAID 10; * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
- Connector & Ports — Internal I/O Ports
- 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x CPU fan header; 1 x system fan header; 1 x M.2 Socket 3 connector; 4 x SATA 6Gb/s connectors; 1 x front panel header; 1 x front panel audio header; 1 x S/PDIF Out header; 1 x CPU cooler LED strip/RGB LED strip header; 1 x USB 3.1 Gen 1 header; 2 x USB 2.0/1.1 headers; 1 x serial port header; 1 x Clear CMOS jumper
- Warranty Information — Manufacturing Warranty
- 03 years
- Connector & Ports — TPM (Trusted Platform Module )
- 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only);
Compare with similar products
 This itemGigabyte B450M DS3H AM4 AMD Micro ATX Motherboard |  AsusASUS PRIME H510M-K R2.0 10th and 11th Gen Micro-ATX Motherboard |  GIGABYTEGIGABYTE H610M K DDR5 Micro ATX Motherboard |  AsusASUS H110M-K Motherboard | |
|---|---|---|---|---|
| Price | ৳10,700 | ৳10,700 | ৳10,700 | ৳10,700 |
| Availability | In stock | In stock | In stock | In stock |
| Brand | GIGABYTE | Asus | GIGABYTE | Asus |
| M.2 slots | 1 | 1 | — | — |
| RAM type | Support for DDR4 3200(O.C.)/2933/2667/2400/2133 MHz memory modules; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules | DDR4 3200(OC)/3000(OC)/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) | Support for 5600/5200/4800/4400 MT/s memory modules; 13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:; 4800/4400 MT/s memory modules; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memor | — |
| Form factor | Micro ATX Form Factor; 24.4cm x 21.5cm | micro-ATX Form Factor; 8.9 inch x 8.0 inch ( 22.6 cm x 20.3 cm ) | Micro ATX Form Factor; 23.0cm x 21.5cm | — |
| Chipset | AMD B450 | Intel H470 Chipset | Intel H610 Express Chipset | Intel® H110 |
| Warranty | — | — | — | 3 Years |
