GIGABYTE H610M K DDR5 Micro ATX Motherboard
Model: H610M K DDR5Item #: gigabyte-h610m-k-ddr5-motherboard
৳10,700৳10,900Save 2%
In stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- Intel H610 Express Chipset
- Support for 5600/5200/4800/4400 MT/s memory modules; 13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:; 4800/4400 MT/s memory modules; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memor RAM type
- Micro ATX Form Factor; 23.0cm x 21.5cm
Overview
The GIGABYTE H610M K DDR5 Micro ATX motherboard is a compact and versatile platform designed to support the latest Intel processors, including the 14th, 13th, and 12th Gen CPUs with an LGA1700 socket. It provides robust performance and future-proofing for various computing needs, from gaming to content creation. This motherboard supports up to 4x DDR5 DIMMs, allowing for a maximum memory capacity of 64GB at speeds up to 3200 MHz, utilizing Dual Channel Non-ECC Unbuffered memory architecture. The GIGABYTE H610M K DDR5 features a single HDMI 2.1 port for high-definition graphics output and is equipped with a Realtek GbE LAN chip that supports up to 1 Gbps network speeds, with additional support for 100 Mbps connections and bandwidth management capabilities. It offers fast storage options through an NVMe PCIe 3.0 x4 M.2 slot, reducing load times for applications and games. High-quality audio capacitors and an audio noise guard ensure clear and immersive sound quality, enhancing the overall user experience. For efficient cooling and noise management, the Smart Fan 6 feature includes multiple temperature sensors and hybrid fan headers with a fan stop function. The motherboard also comes with the GIGABYTE APP Center, a user-friendly interface for managing system settings and features. Designed for durability, the GIGABYTE H610M K DDR5 incorporates an Anti-Sulfur resistor design, enhancing the longevity and reliability of the components. This motherboard is an excellent choice for building a high-performance PC with the latest technology and features.
Buy GIGABYTE H610M K DDR5 Micro ATX Motherboard from the best Motherboard Shop in BD
Specifications
- Chipset
- Intel H610 Express Chipset
- RAM type
- Support for 5600/5200/4800/4400 MT/s memory modules; 13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:; 4800/4400 MT/s memory modules; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memor
- Form factor
- Micro ATX Form Factor; 23.0cm x 21.5cm
- Memory — Type
- DDR5
- Memory — Slots
- 2 x DIMM sockets
- Highlights — Model
- H610M K DDR5
- Graphics — Graphics
- Integrated Graphics Processor-Intel HD Graphics support:; - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz; * Support for HDMI 2.1 version and HDCP 2.3.; ** Support native HDMI 2.1 TMDS compatible ports.; ; ; - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz; * Support for DisplayPort 1.2 version and HDCP 2.3; ; ; (Graphics specifications may vary depending on CPU support.)
- Expansion Slots — PCI
- CPU:; - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16; Chipset:; - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Show all 25 specificationsShow fewer
- Highlights — Features
- Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
- Memory — Maximum Memory
- Supporting up to 128 GB (64 GB single DIMM capacity) of system memory
- Basic Information — BIOS
- 1 x 128 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- Connector & Ports — HDMI
- 1 x HDMI port
- Basic Information — Audio
- Realtek Audio CODEC; High Definition Audio; 2/4/5.1/7.1-channel; * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.; Support for S/PDIF Out
- Others — Bundled Software
- Norton Internet Security (OEM version); LAN bandwidth management software
- Others — Special Features
- iTE I/O Controller Chip
- Highlights — Supported RAM
- 2x DDR5, Max 128GB 5333(OC)
- Connector & Ports — USB (s)
- Chipset:; - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header); - 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
- Highlights — Graphics Output
- 1x HDMI 2.1, 1 x DisplayPort
- Connector & Ports — LAN Port (s)
- Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
- Basic Information — Supported CPU
- LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core, Pentium Gold and Celeron Processors; L3 cache varies with CPU; (Please refer "CPU Support List" for more information.)
- Connector & Ports — Display Port (s)
- 1 x DisplayPort
- Connector & Ports — Supported Storage
- Chipset:; - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 3.0 x4/x2 SSD support); - 2 x SATA 6Gb/s connectors
- Connector & Ports — Internal I/O Ports
- Internal I/O Connectors; 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x CPU fan header; 1 x system fan header; 1 x M.2 Socket 3 connector; 2 x SATA 6Gb/s connectors; 1 x front panel header; 1 x front panel audio header; 1 x USB 3.2 Gen 1 header; 1 x USB 2.0/1.1 header; 1 x Clear CMOS jumper; ; Back Panel Connectors; 1 x HDMI port; 1 x DisplayPort; 2 x USB 3.2 Gen 1 ports; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 3 x audio jacks
- Warranty Information — Manufacturing Warranty
- 3 years Warranty
- Connector & Ports — TPM (Trusted Platform Module )
- 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
Compare with similar products
 This itemGIGABYTE H610M K DDR5 Micro ATX Motherboard |  AsusASUS PRIME H510M-K R2.0 10th and 11th Gen Micro-ATX Motherboard |  GIGABYTEGigabyte B450M DS3H AM4 AMD Micro ATX Motherboard |  AsusASUS H110M-K Motherboard | |
|---|---|---|---|---|
| Price | ৳10,700 | ৳10,700 | ৳10,700 | ৳10,700 |
| Availability | In stock | In stock | In stock | In stock |
| Brand | GIGABYTE | Asus | GIGABYTE | Asus |
| RAM type | Support for 5600/5200/4800/4400 MT/s memory modules; 13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:; 4800/4400 MT/s memory modules; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memor | DDR4 3200(OC)/3000(OC)/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) | Support for DDR4 3200(O.C.)/2933/2667/2400/2133 MHz memory modules; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules | — |
| Form factor | Micro ATX Form Factor; 23.0cm x 21.5cm | micro-ATX Form Factor; 8.9 inch x 8.0 inch ( 22.6 cm x 20.3 cm ) | Micro ATX Form Factor; 24.4cm x 21.5cm | — |
| Chipset | Intel H610 Express Chipset | Intel H470 Chipset | AMD B450 | Intel® H110 |
| M.2 slots | — | 1 | 1 | — |
| Warranty | — | — | — | 3 Years |
