GIGABYTE B650 EAGLE AX DDR5 AM5 Motherboard

Name: GIGABYTE B650 EAGLE AX DDR5 AM5 Motherboard
Brand: GIGABYTE
Price: 25500 BDT
Availability: InStock

Model: B650 EAGLE AXItem #: gigabyte-b650-eagle-ax-motherboard

৳25,500~~৳26,500~~Save 4%

In stockverified 22 Sept 2026

Ordering is paused

We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.

Delivery

Inside Dhaka: ৳60 · 1–2 days
Outside Dhaka: ৳120 · 2–4 days

Sold by Micro

Key highlights

AMD B650 Chipset
7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules; Dual channel memory architecture; Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules; (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.) RAM type
ATX Form Factor; 30.5cm x 24.4cm

Overview

The GIGABYTE B650 EAGLE AX DDR5 AM5 Motherboard is designed to support AMD's latest Ryzen 7000 and 8000 series processors, offering unparalleled performance for both gaming and professional applications. This motherboard features a robust 12+2+2 phase digital VRM solution, ensuring stable power delivery and efficient performance under heavy workloads. With its dual-channel DDR5 memory support, the board includes 4 SMD DIMM slots compatible with AMD EXPO and Intel XMP memory modules, providing enhanced performance and flexibility. The motherboard's SuperSpeed storage features, which include two PCIe 4.0 M.2 and one PCIe 5.0 M.2 connection, allow for quick data access and transfer. VRM power stability and excellent performance for 25110 M.2 SSDs are guaranteed by its sophisticated thermal design, which includes an M.2 thermal protection. With its rapid-release design and hassle-free maintenance and upgrades, the EZ-Latch PCIe x16 slot makes expansion simple. Gigabit Ethernet LAN for dependable wired networking and Wi-Fi 6E 802.11ax for quick wireless connectivity are examples of networking capabilities. The board offers a wide range of connectivity choices, including back USB, HDMI, and DisplayPort ports that can carry data at up to 10 Gbps. Smart Fan 6 efficiently controls cooling with its various temperature sensors and hybrid fan headers that include a fan stop functionality to keep the system cooled at its best. Updating the system firmware is made easier for customers by the Q-Flash Plus function, which enables BIOS updates without requiring the installation of a CPU, RAM, or graphics card. For those looking for cutting-edge performance and dependability, the GIGABYTE B650 EAGLE AX DDR5 AM5 Motherboard offers a comprehensive solution. As such, it's a great option for both enthusiasts and professionals.

Specifications

Chipset: AMD B650
RAM type: 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules; Dual channel memory architecture; Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules; (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
Form factor: ATX Form Factor; 30.5cm x 24.4cm
Memory — Type: DDR5
Memory — Slots: 4 DIMMs
Highlights — Model: B650 EAGLE AX
Graphics — Graphics: Integrated Graphics Processor with AMD Radeon™ Graphics support:; - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz; * Support for DisplayPort 1.4 version.; ; ; - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz; * Support for HDMI 2.1 version and HDCP 2.3.; ** Support for native HDMI 2.1 TMDS compatible ports.; ; ; (Graphics specifications may vary depending on CPU support.)
Expansion Slots — PCI: 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:; - AMD Ryzen 7000 Series Processors support PCIe 4.0 x16 mode; - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode; - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode; * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.; ; 2 x PCI Express x16 slots (PCIEX1_1/PCIEX1_2), integrated in the CPU, supporting PCIe 3.0 and running at x1; * The PCIEX1_1 and PCIEX1_2 slots become unavailable when an AMD Ryzen™ 8000 Series-Phoenix 2 processor is used.; 1 x PCI Express x16 slot (PCIEX1_3), integrated in the Chipset, supporting PCIe 3.0 and running at x1

Show all 28 specifications

Highlights — Features: Realtek GbE LAN chip & Realtek Wi-Fi 6E RTL8852CE
Memory — Maximum Memory: 192GB
Basic Information — BIOS: 1 x 256 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Connector & Ports — HDMI: 1x HDMI
Connector & Ports — RAID: RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices; RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Basic Information — Audio: Realtek Audio CODEC; High Definition Audio; 2/4/5.1/7.1-channel; * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Connector & Ports — Audio: 3 x Audio jacks
Others — Bundled Software: Norton Internet Security (OEM version); LAN bandwidth management software
Others — Special Features: Support for GIGABYTE Control Center (GCC); * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.; ; ; Support for Q-Flash; Support for Q-Flash Plus
Highlights — Supported RAM: 4x DDR5, up to 192GB, 7600(OC)
Connector & Ports — USB (s): CPU:; - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel; - 1 x USB Type-C port on the back panel, with USB 3.2 Gen 1 support; CPU+USB 2.0 Hub:; - 4 x USB 2.0/1.1 ports on the back panel; Chipset:; - 2 x USB 3.2 Gen 1 ports available through the internal USB header; - 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header; - 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header); Chipset+USB 2.0 Hub:; - 4 x USB 2.0/1.1 ports available through the internal USB headers
Highlights — Graphics Output: 1x Display Port, 1 x HDMI
Connector & Ports — LAN Port (s): Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Basic Information — Supported CPU: AMD Socket AM5, support for: AMD Ryzen 8000/ 7000 Series Processors
Connector & Ports — Display Port (s): 1 x DisplayPorts
Connector & Ports — Supported Storage: 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:; - AMD Ryzen 7000 Series Processors support PCIe 5.0 x4/x2 SSDs; - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs; - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs; ; 1 x M.2 connector (M2P_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:; - AMD Ryzen 7000 Series Processors support PCIe 4.0 x2 SSDs; - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x2 SSDs; - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs; ; 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support); 4 x SATA 6Gb/s connectors
Connector & Ports — Internal I/O Ports: Internal I/O Connectors; 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x CPU fan header; 1 x CPU fan/water cooling pump header; 2 x system fan headers; 1 x system fan/water cooling pump header; 3 x addressable RGB Gen2 LED strip headers; 1 x RGB LED strip header; 3 x M.2 Socket 3 connectors; 4 x SATA 6Gb/s connectors; 1 x front panel header; 1 x front panel audio header; 1 x USB Type-C header, with USB 3.2 Gen 1 support; 1 x USB 3.2 Gen 1 header; 3 x USB 2.0/1.1 headers; 1 x Q-Flash Plus button; 1 x serial port header j; 1 x Clear CMOS jumper; ; Back Panel Connectors; 1 x DisplayPort; 1 x HDMI port; 1 x PS/2 keyboard/mouse port; 2 x SMA antenna connectors (2T2R); 1 x USB Type-C port, with USB 3.2 Gen 1 support; 2 x USB 3.2 Gen 2 Type-A ports (red); 6 x USB 2.0/1.1 ports; 1 x RJ-45 port; 3 x audio jacks
Warranty Information — Manufacturing Warranty: 3 Years
Connector & Ports — Wireless Communication module: Realtek Wi-Fi 6E RTL8852CE; - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands; - BLUETOOTH 5.3; - Support for 11ax 160MHz wireless standard; (Actual data rate may vary depending on environment and equipment.)
Connector & Ports — TPM (Trusted Platform Module ): 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)

Compare with similar products

	This itemGIGABYTE B650 EAGLE AX DDR5 AM5 Motherboard	ASRockASRock B850M Pro RS WiFi AM5 mATX Motherboard	MSIMSI MAG B760M MORTAR WIFI II DDR5 mATX Motherboard	AsusAsus TUF GAMING B760-PLUS WIFI D4 ATX Motherboard
Price	৳25,500	৳25,500	৳25,500	৳25,500
Availability	In stock	In stock	In stock	Out of stock
Brand	GIGABYTE	ASRock	MSI	Asus
RAM type	7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules; Dual channel memory architecture; Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules; (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)	- Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC); - Max. capacity of system memory: 256GB; - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules	Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz; Max. overclocking frequency:; • 1DPC 1R Max speed up to 7800+ MHz; • 1DPC 2R Max speed up to 6600+ MHz; • 2DPC 1R Max speed up to 6400+ MHz; • 2DPC 2R Max speed up to 5600+ MHz; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Intel Extreme Memory Profile	ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP); OptiMem II
Form factor	ATX Form Factor; 30.5cm x 24.4cm	Micro ATX Form Factor: 9.6-in x 9.6-in, 24.4 cm x 24.4 cm	mATX; 243.84mmx243.84mm	ATX Form Factor; 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
Chipset	AMD B650	AMD B850	INTEL B760	Intel B760 Chipset
M.2 slots	—	1	3	3
