MSI B450M-A PRO MAX II AMD AM4 Motherboard
Model: B450M-A PRO MAX IIItem #: msi-b450m-a-pro-max-ii-motherboard
৳7,700
Out of stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- AMD B450 Chipset
- Memory Support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE); Supports Dual-Channel mode; Supports non-ECC, UDIMM memory; Supports ECC UDIMM memory (non-ECC mode); Supports un-buffered memory RAM type
- mATX; 200mmx236mm Form factor
Overview
The MSI B450M-A PRO MAX II AMD AM4 Motherboard is designed to support a wide range of processors, from AMD Ryzen 5000 Series to Athlon with Radeon Vega Graphics desktop processors, it ensures versatility. With support for DDR4 Memory up to 4133 (OC) MHz, it delivers rapid and efficient performance. The Turbo M.2 feature, running at PCI-E Gen3 x4, maximizes the performance of NVMe based SSDs. Experience studio-grade sound quality with Audio Boost, while the 2.5G LAN provides an upgraded network solution for professional and multimedia use. X-Boost software detects and enhances the performance of storage and USB devices, adding convenience. With Core Boost, the motherboard features a premium layout and fully digital power design, ensuring support for more cores and improved performance. The MSI B450M-A PRO MAX II AMD AM4 Motherboard combines aesthetics, power, and functionality for a dynamic computing experience.
Specifications
- Chipset
- AMD B450
- RAM type
- Memory Support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE); Supports Dual-Channel mode; Supports non-ECC, UDIMM memory; Supports ECC UDIMM memory (non-ECC mode); Supports un-buffered memory
- Form factor
- mATX; 200mmx236mm
- Memory — Type
- DDR4
- Memory — Slots
- 2
- Highlights — Model
- B450M-A PRO MAX II
- Graphics — Graphics
- 1x HDMI; Support HDMITM 1.4, maximum resolution of 4K 24Hz; 1x DVI; Support DVI-D, maximum resolution of 1920x1200 60Hz
- Expansion Slots — PCI
- 1x PCI-E x16 slot; 1x PCI-E x1 slot; PCI_E1 Gen PCIe 3.0 supports up to x16 (From CPU); PCI_E2 Gen PCIe 2.0 supports up to x1 (From Chipset)
Show all 23 specificationsShow fewer
- Highlights — Features
- 1 x M.2 Slot, Realtek 8125 2.5Gbps LAN
- Memory — Maximum Memory
- 64GB
- Connector & Ports — HDMI
- 1x HDMI
- Connector & Ports — RAID
- Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
- Basic Information — Audio
- Realtek ALC897 Codec; 7.1-Channel High Definition Audio
- Highlights — Supported RAM
- 2x DDR4, up to 4133 (OC) MHz
- Connector & Ports — USB (s)
- 2x USB 2.0 (Rear); 4x USB 2.0 (Front); 4x USB 3.2 Gen1 Type A (Rear); 2x USB 3.2 Gen1 Type A (Front)
- Highlights — Graphics Output
- 1 x HDMI, 1x DVI
- Connector & Ports — DVI-D (s)
- 1x DVI
- Connector & Ports — LAN Port (s)
- Realtek 8125 2.5Gbps LAN controller
- Basic Information — Supported CPU
- Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, 3000 G-Series, 2000 Series, 2000 G-Series and 1000 Series Desktop Processor and Athlon with Radeon Vega Graphics desktop processors; Socket AM4
- Connector & Ports — Supported Storage
- 1x M.2; M.2_1 Source (From CPU) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260/2242 devices; 4x SATA 6G
- Connector & Ports — Internal I/O Ports
- 1x Power Connector(ATX_PWR); 1x Power Connector(CPU_PWR); 1x CPU Fan; 1x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 4x USB 2.0 ports; 2x USB 3.2 Gen1 Type A ports
- Warranty Information — Manufacturing Warranty
- 03 Years Warranty
- Connector & Ports — TPM (Trusted Platform Module )
- 1x TPM pin header(Support TPM 2.0)
Compare with similar products
 This itemMSI B450M-A PRO MAX II AMD AM4 Motherboard |  ColorfulColorful BATTLE-AX B450M-K M.2 V14 AM4 mATX Motherboard |  MSIMSI A520M-A Pro AM4 AMD Micro-ATX Motherboard |  AsusAsus Prime A520M-A Micro ATX AM4 Motherboard | |
|---|---|---|---|---|
| Price | ৳7,700 | ৳7,700 | ৳7,800 | ৳8,000 |
| Availability | Out of stock | Out of stock | In stock | Out of stock |
| Brand | MSI | Colorful | MSI | Asus |
| RAM type | Memory Support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE); Supports Dual-Channel mode; Supports non-ECC, UDIMM memory; Supports ECC UDIMM memory (non-ECC mode); Supports un-buffered memory | Support DDR4-4000(OC)/3733(OC)/3600(OC)/3466(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2666/2400/2133MHz memory; Support Extreme Memory Profile (XMP) memory technology; Supports dual channel memory technology | Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC; Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE; 1DPC 1R max speed 4600 MHz; 1DPC 2R max speed 3866 MHz; Supports non-ECC UDIMM memory; Supports ECC UDIMM memory (non-ECC mode); Supports un-buffered memory | 4800(O.C.)/ 4600(O.C)/ 4466(O.C.)/ 4400(O.C)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3333(O.C.)/ 3200/3000/ 2800/2666/ 2400/ 2133 MHz Un-buffered Memory; ECC Memory (ECC mode) support varies by CPU |
| Form factor | mATX; 200mmx236mm | M-ATX; 230mm x 197mm | Micro-ATX Form Factor; 9.3 in. x 7.9 in. (23.6 cm x 20 cm) | mATX Form Factor; 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) |
| Chipset | AMD B450 | AMD B450 | AMD B520 | AMD A520 |
| M.2 slots | — | 1 | 1 | 1 |
