Shop all MSI products
MSI MAG B860M MORTAR WIFI LGA 1851 mATX Motherboard
Model: MAG B860M MORTAR WIFIItem #: msi-mag-b860m-mortar-wifi-motherboard
৳35,000
Out of stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- INTEL B860 Chipset
- 3 M.2 slots
- Memory Support 9066 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 9200+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 6400+ MT/s; • 2DPC 2R Max speed up to 5600+ MT/s; Supports Intel POR Speed and JEDEC Speed; Supports Memory Overclocking and Intel® XMP 3.0; Supports Dual-Controller Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM RAM type
- mATX; 243.84mmx243.84mm Form factor
Overview
The MSI MAG B860M MORTAR WIFI LGA 1851 mATX motherboard is a reliable mATX choice. It offers a state-of-the-art platform for professionals, producers, and gamers and is made for Intel Core Ultra Processors (Series 2) with an LGA 1851 socket. This MSI Intel Core Ultra Series motherboard offers outstanding performance and multitasking capabilities. It supports DDR5 memory with speeds up to 9200+ MT/s (overclocked) and a maximum capacity of 256GB. Reliability and efficiency are guaranteed by its sturdy 12+1+1+1 Duet Rail Power System with 60A DrMOS, dual 8-pin CPU power connectors, Core Boost, and Memory Boost. Server-grade components and a 6-layer PCB with 2 ounces of thicker copper improve stability and longevity in this MSI MAG B860M MORTAR WIFI mATX DDR5 motherboard. High-quality MOSFET thermal pads, an expanded heatsink, and the EZ M.2 Shield Frozr II for optimal cooling are all included in the Frozr Guard for improved thermal management. With its PCIe 5.0 x16 slot and support for Lightning Gen 5 x4 M.2, this MSI MAG B860M MORTAR WIFI LGA1851 mATX motherboard offers lightning-fast gaming and storage performance. With an Intel Killer 5G LAN, a Thunderbolt 4 port that supports data transfer rates up to 40Gbps, and Wi-Fi 7 for dependable and quick networking, this MSi LGA1851 motherboard provides extensive connectivity. Several USB 10Gbps and 5Gbps ports, as well as USB 40Gbps Type-C, are available for seamless connectivity with contemporary devices. With onboard graphics options like HDMI 2.1, DisplayPort 1.4, and Thunderbolt-enabled Type-C DisplayPort, this MSI MAG B860M MORTAR WIFI LGA 1851 mATX motherboard supports up to 8K at 60Hz or 4K at 120Hz for rich visuals. It delivers plenty of storage and high-end sound quality thanks to its three M.2 slots, four SATA 6G connections, support for RAID 0, 1, 5, and 10, and Realtek ALC897 7.1-channel audio. Advanced wireless communication is offered by the Intel Killer Wi-Fi 7 and Bluetooth 5.4, and its small mATX form factor guarantees adaptability. The MSI MAG B860M MORTAR WIFI motherboard is designed for outstanding performance and efficiency, and it is compatible with Windows 11.
Specifications
- Chipset
- INTEL B860
- M.2 slots
- 3
- RAM type
- Memory Support 9066 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 9200+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 6400+ MT/s; • 2DPC 2R Max speed up to 5600+ MT/s; Supports Intel POR Speed and JEDEC Speed; Supports Memory Overclocking and Intel® XMP 3.0; Supports Dual-Controller Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM
- Form factor
- mATX; 243.84mmx243.84mm
- Memory — Type
- DDR5
- Memory — Slots
- 4x UDIMM
- Highlights — Model
- MAG B860M MORTAR WIFI
- Graphics — Graphics
- 1x HDMI; Support HDMI 2.1 with FRL, maximum resolution of 8K 60Hz; 1x DisplayPort; Support DisplayPort 1.4, maximum resolution of 4K 60Hz; 1x Type-C DisplayPort; Thunderbolt 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz
Show all 26 specificationsShow fewer
- Expansion Slots — PCI
- 1x PCI-E x16 slot; 1x PCI-E x4 slot; PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU); PCI_E2 Gen PCIe 4.0 supports up to x4 (From Chipset)
- Highlights — Features
- 3x M.2 Slot, 1x 5Gbps LAN, Intel Killer Wi-Fi 7, Bluetooth 5.4
- Memory — Maximum Memory
- 256GB
- Connector & Ports — HDMI
- 1x HDMI 2.1 with FRL
- Connector & Ports — RAID
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Basic Information — Audio
- Realtek ALC897 Codec; 7.1-Channel High Definition Audio; Supports S/PDIF output
- Connector & Ports — Audio
- 1x Front Audio (JAUD)
- Others — Special Features
- 4x EZ Debug LED; 1x EZ Memory Detection LED
- Highlights — Supported RAM
- 4x DDR5, Dual Channel 9200+ MT/s (OC), Max 256GB
- Connector & Ports — USB (s)
- 4x USB 2.0 (Rear); 4x USB 2.0 (Front); 2x USB 5Gbps Type A (Front); 3x USB 10Gbps Type A (Rear); 1x USB 10Gbps Type C (Rear); 1x USB 10Gbps Type C (Front)
- Highlights — Graphics Output
- 1x HDMI, 1x DisplayPort, 1x Type-C DisplayPort
- Connector & Ports — LAN Port (s)
- Intel Killer E5000 5Gbps LAN
- Basic Information — Supported CPU
- Supports Intel Core Ultra Processors (Series 2); LGA 1851
- Connector & Ports — Display Port (s)
- 1x DisplayPort 1.4; 1x Type-C DisplayPort; Thunderbolt 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz
- Connector & Ports — Supported Storage
- 3x M.2; M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices; M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices; M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices; 4x SATA 6G
- Connector & Ports — Internal I/O Ports
- 1x Thunderbolt5 card connector(JTBT5, support RTD3); 1x Power Connector(ATX_PWR); 2x Power Connector(CPU_PWR); 1x Power Connector(PCIE_PWR 8pin); 1x CPU Fan; 1x Combo Fan (Pump_Sys Fan); 4x System Fan; 1x EZ Conn-header (JAF_1); 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Tuning Controller connector(JDASH); 3x Addressable V2 RGB LED connector (JARGB_V2); 1x RGB LED connector(JRGB); 1x TPM pin header(Support TPM 2.0); 4x USB 2.0 ports; 2x USB 5Gbps Type A ports; 1x USB 10Gbps Type C ports
- Warranty Information — Manufacturing Warranty
- 3 Year
- Connector & Ports — Wireless Communication module
- Intel Killer BE1750x Wi-Fi 7; The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps; Supports 802.11 a/ b/ g/ n/ ac/ ax/ be; Supports Bluetooth 5.4, MLO, 4KQAM
Compare with similar products
 This itemMSI MAG B860M MORTAR WIFI LGA 1851 mATX Motherboard |  ASRockASRock X870 Pro RS WiFi AM5 DDR5 ATX Motherboard |  MSIMSI Z790 GAMING PRO WIFI ATX Motherboard |  GIGABYTEGIGABYTE B850 AORUS ELITE WIFI7 DDR5 AMD AM5 ATX Motherboard | |
|---|---|---|---|---|
| Price | ৳35,000 | ৳35,000 | ৳35,000 | ৳35,000 |
| Availability | Out of stock | In stock | Out of stock | Out of stock |
| Brand | MSI | ASRock | MSI | GIGABYTE |
| M.2 slots | 3 | 1 | — | 1 |
| RAM type | Memory Support 9066 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s; Max. overclocking frequency:; • 1DPC 1R Max speed up to 9200+ MT/s; • 1DPC 2R Max speed up to 7200+ MT/s; • 2DPC 1R Max speed up to 6400+ MT/s; • 2DPC 2R Max speed up to 5600+ MT/s; Supports Intel POR Speed and JEDEC Speed; Supports Memory Overclocking and Intel® XMP 3.0; Supports Dual-Controller Dual-Channel mode; Supports Non-ECC, Un-buffered memory; Supports CUDIMM | Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC); Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules | Memory Support 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz; Max. overclocking frequency:; • 1DPC 1R Max speed up to 7200+ MHz; • 1DPC 2R Max speed up to 6400+ MHz; • 2DPC 1R Max speed up to 6000+ MHz; • 2DPC 2R Max speed up to 5600+ MHz; ; Supports Intel XMP 3.0 OC; Supports Dual-Controller Dual-Channel mode; Supports non-ECC, un-buffered memory | Support for DDR5 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s memory modules |
| Form factor | mATX; 243.84mmx243.84mm | ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm; 8 Layer PCB | ATX; 243.84mmx304.8mm | ATX Form Factor; 30.5cm x 24.4cm |
| Chipset | INTEL B860 | AMD X870 | INTEL Z790 | AMD B850 |
