MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard

Name: MSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard
Brand: MSI
Price: 15600 BDT
Availability: OutOfStock

Model: MSI B550M Pro-VDH WiFiItem #: msi-b550m-pro-vdh-wi-fi-motherboard

৳15,600

Out of stockverified 22 Sept 2026

Ordering is paused

We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.

Delivery

Inside Dhaka: ৳60 · 1–2 days
Outside Dhaka: ৳120 · 2–4 days

Sold by Micro

Key highlights

AMD B550 Chipset
2 M.2 slots
Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC; Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE; 1DPC 1R max speed 4400 MHZ; 1DPC 2R max speed 3733 MHZ; 2DPC 1R max speed 3866 MHZ; 2DPC 2R max speed 3466 MHZ; Supports non-ECC UDIMM memory; Supports ECC UDIMM memory; Supports un-buffered memory RAM type
Micro-ATX Form Factor; 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)

Overview

PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity. With more cores’ processors, thermal and power design is more important to make sure the temperature keeps lower. MSI extended PWM heatsink with 7W/mK thermal pad ensures even high-end processors to run at full speed with MSI motherboards. The world’s fastest SSDs can start to lower performance when getting hot. Part of the motherboards heatsink design, M.2 SHIELD FROZR is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance. MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically. Designed to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked ‘keep-out-zone’ allows for easy and safe installation and a perfect fit. MSI PRO Series motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Higher efficiency makes your work easier. Utilizing 3rd Gen Ryzen processors, MSI B550 motherboards feature the latest Lightning Gen 4 M.2 which is the fastest onboard storage solution on the market with up to 64 Gb/s transfer speed. An enhanced PCB design with 2oz thickened copper increases conductivity, improving heat dissipation and performance reliability especially during overclocking. Unleash and sustain maximum performance with an aggressive VRM design built with a total of 10 phases Digital Power with Doubler Design. Combining exclusive Core Boost technology, the PRO series motherboard is ready to sustain heavy daily work. MSI lightning Gen 4 PCI-E is the latest and the fastest PCI-E data transfer solution with 64GB/s of unidirectional transfer bandwidth that has doubled compared to its previous generation. PCIe 4.0 maintains both backward and forward compatibility with older and newer specifications. Optimized by steel armor design and server-grade PCB, you can enjoy next-gen devices without any compromise. MSI OC LAB does not merely work hard on extreme overclocking. Compared to the B450 motherboard memory A-XMP profile, MSI does have great improvement in performance and efficiency for B550 motherboards. Easy to enable A-XMP profile with auto power settings to get the best memory speed and stability. Core Boost technology combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU but also creating the perfect conditions for your CPU overclocking.

Specifications

Chipset: AMD B550
M.2 slots: 2
RAM type: Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC; Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE; 1DPC 1R max speed 4400 MHZ; 1DPC 2R max speed 3733 MHZ; 2DPC 1R max speed 3866 MHZ; 2DPC 2R max speed 3466 MHZ; Supports non-ECC UDIMM memory; Supports ECC UDIMM memory; Supports un-buffered memory
Form factor: Micro-ATX Form Factor; 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
Memory — Type: Dual-channel memory architecture
Memory — Slots: 4x DDR4 memory slots
Highlights — Model: MSI B550M Pro-VDH WiFi
Graphics — Graphics: 1x VGA port, supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz ; 1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz; 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz

Show all 22 specifications

Expansion Slots — PCI: 1x PCIe 4.0/ 3.0 x16 slot (PCI_E1); 2x PCIe 3.0 x1 slots
Memory — Maximum Memory: 128GB
Connector & Ports — HDMI: 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz
Connector & Ports — Audio: Realtek ALC892 Codec; 7.1-Channel High Definition Audio
Others — Special Features: WIRELESS LAN & BLUETOOTH:; Intel Dual Band Wireless-AC 3168-; Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 433 Mbps speed.; Supports Dual Mode Bluetooth 2.1,2.1+EDR,3.0,4.0,BLE,4.2
Connector & Ports — USB (s): AMD B550 Chipset; 3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector); 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors); AMD Processor; 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
Graphics — Max Shared Memory: 16GB
Connector & Ports — LAN Port (s): 1x Realtek 8111HN Gigabit LAN controller
Basic Information — Supported CPU: AMD Ryzen 5000/4000G Series & AMD Ryzen 3rd Generation Processors
Connector & Ports — Display Port (s): 1x DisplayPort supports a maximum resolution of 4096x2160 @60Hz
Connector & Ports — Supported Storage: AMD B550 Chipset; 4x SATA 6Gb/s ports; 2x M.2 slots (Key M); M2_1 slot (from AMD Processor); Supports PCIe 4.0/ 3.0 x4; Supports SATA 6Gb/s; Supports 2242/ 2260/ 2280 storage devices; M2_2 slot (from AMD B550 chipset); Supports PCIe 3.0x4; Supports 2242/ 2260/ 2280 storage devices
Connector & Ports — Internal I/O Ports: 1x 24-pin ATX main power connector; 1x 8-pin ATX 12V power connector; 4x SATA 6Gb/s connectors; 2x M.2 slots (M-Key); 1x USB 3.2 Gen 1 5Gbps Type-C port; 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports); 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports); 1x 4-pin CPU fan connector; 1x 4-pin water-pump fan connector; 3x 4-pin system fan connectors; 1x Front panel audio connector; 2x System panel connectors; 1x Serial port connector; 1x Chassis Intrusion connector; 2x 4-pin RGB LED connectors; 2x 3-pin RAINBOW LED connectors; 1x Clear CMOS jumper
Warranty Information — Manufacturing Warranty: 03 Years Warranty
Connector & Ports — TPM (Trusted Platform Module ): 1 x TPM module connector;
