MSI PRO B760M-G mATX Motherboard
Model: PRO B760M-GItem #: msi-pro-b760m-g-motherboard
৳15,700
Out of stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- INTEL B760 Chipset
- DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC); Max. overclocking frequency:; • 1DPC 1R Max speed up to 6400+ MHz; • 1DPC 2R Max speed up to 5600+ MHz; Supports Intel XMP 3.0 OC; Supports Dual-Controller Dual-Channel mode; Supports non-ECC, un-buffered memory RAM type
- mATX; 220mmx243.84mm Form factor
Overview
The MSI PRO B760M-G is a micro-ATX motherboard with an LGA 1700 socket that supports 14th, 13th and 12th-generation Intel Core, Pentium Gold, and Celeron CPUs. For quicker performance, it supports DDR5 memory and has Dual-channel DDR5 6400+(OC) capabilities. Core Boost, a premium layout, and a digital power architecture enable the motherboard to accommodate more cores and give higher performance. Memory Boost, an innovative technology that produces pure data signals for the highest performance, stability, and compatibility, is also incorporated. The 14th Gen Motherboard has PCIe 4.0 and Lightning Gen4 x4 M.2 for a lightning-fast experience. This enables faster data transmission rates and enhanced performance for gaming and other high-performance applications. It comes with an upgraded network solution for professional and multimedia use. Delivers a secure, stable, and fast network connection. The motherboard has AUDIO BOOST, which delivers studio-quality sound for the most immersive gaming experience. Steel Armor is also incorporated to prevent VGA cards from bending and EMI, resulting in improved performance, stability, and strength.
Buy MSI PRO B760M-G mATX Motherboard Shop in BD
Specifications
- Chipset
- INTEL B760
- RAM type
- DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC); Max. overclocking frequency:; • 1DPC 1R Max speed up to 6400+ MHz; • 1DPC 2R Max speed up to 5600+ MHz; Supports Intel XMP 3.0 OC; Supports Dual-Controller Dual-Channel mode; Supports non-ECC, un-buffered memory
- Form factor
- mATX; 220mmx243.84mm
- Memory — Type
- DDR5
- Memory — Slots
- 2
- Highlights — Model
- PRO B760M-G
- Graphics — Graphics
- 1x HDMI; Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz*; 1x DisplayPort; Support DP 1.4, maximum resolution of 4K 60Hz*; 1x VGA; Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz
- Expansion Slots — PCI
- 1x PCI-E x16 slot; 1x PCI-E x1 slot; PCI_E1 Gen PCIe 4.0 supports up to (From CPU); PCI_E2 Gen PCIe 4.0 supports up to (From Chipset)
Show all 25 specificationsShow fewer
- Highlights — Features
- 2x M.2 slot, Realtek RTL8125B 2.5Gbps LAN
- Memory — Maximum Memory
- 96GB
- Connector & Ports — HDMI
- 1x HDMI
- Connector & Ports — RAID
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Basic Information — Audio
- Realtek ALC897 Codec; 7.1-Channel High-Definition Audio
- Others — Special Features
- 4x EZ Debug LED
- Highlights — Supported RAM
- 2x DDR5, Max 96GB 6400+(OC)
- Connector & Ports — USB (s)
- 2x USB 2.0 (Rear); 4x USB 2.0 (Front); 4x USB 3.2 Gen1 Type A (Rear); 2x USB 3.2 Gen1 Type A (Front)
- Connector & Ports — VGA (s)
- 1x VGA
- Highlights — Graphics Output
- 1x HDMI, 1x DP, 1x VGA
- Connector & Ports — LAN Port (s)
- Realtek RTL8125B 2.5Gbps LAN
- Basic Information — Supported CPU
- Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold and Celeron Processors; LGA 1700
- Connector & Ports — Display Port (s)
- 1x DisplayPort
- Connector & Ports — Supported Storage
- 2x M.2; M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices; M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices; 4x SATA 6G
- Connector & Ports — Internal I/O Ports
- 1x Power Connector(ATX_PWR); 1x Power Connector(CPU_PWR); 1x CPU Fan; 2x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x Com Port (JCOM); 2x Addressable V2 RGB LED connector (JARGB_V2); 1x RGB LED connector(JRGB); 4x USB 2.0 ports; 2x USB 3.2 Gen1 Type A ports
- Warranty Information — Manufacturing Warranty
- 3 years
- Connector & Ports — TPM (Trusted Platform Module )
- 1x TPM pin header(Support TPM 2.0)
Compare with similar products
 This itemMSI PRO B760M-G mATX Motherboard |  MSIMSI B550M Pro-VDH Wi-Fi AM4 AMD Micro-ATX Motherboard |  MSIMSI PRO B550M-P WIFI6E AMD AM4 mATX Motherboard |  GIGABYTEGIGABYTE B760M D2H mATX Motherboard | |
|---|---|---|---|---|
| Price | ৳15,700 | ৳15,600 | ৳15,700 | ৳15,700 |
| Availability | Out of stock | Out of stock | In stock | Out of stock |
| Brand | MSI | MSI | MSI | GIGABYTE |
| RAM type | DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC); Max. overclocking frequency:; • 1DPC 1R Max speed up to 6400+ MHz; • 1DPC 2R Max speed up to 5600+ MHz; Supports Intel XMP 3.0 OC; Supports Dual-Controller Dual-Channel mode; Supports non-ECC, un-buffered memory | Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC; Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400+ MHz by A-XMP OC MODE; 1DPC 1R max speed 4400 MHZ; 1DPC 2R max speed 3733 MHZ; 2DPC 1R max speed 3866 MHZ; 2DPC 2R max speed 3466 MHZ; Supports non-ECC UDIMM memory; Supports ECC UDIMM memory; Supports un-buffered memory | Memory Support DDR4 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400+ MHz by A-XMP OC MODE; Max. overclocking frequency:; • 1DPC 1R Max speed up to 4400+ MT/s; • 1DPC 2R Max speed up to 3733+ MT/s; • 2DPC 1R Max speed up to 3866+ MT/s; • 2DPC 2R Max speed up to 3466+ MT/s; Supports JEDEC Speed; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports Memory Overclocking by A-XMP OC mode | Support for DDR5 8000(O.C.) /7800(O.C.) /7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules |
| Form factor | mATX; 220mmx243.84mm | Micro-ATX Form Factor; 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm) | mATX; 243.84mmx243.84mm | Micro ATX Form Factor; 24.4cm x 24.4cm |
| Chipset | INTEL B760 | AMD B550 | AMD B550 | Intel B760 Express Chipset |
| M.2 slots | — | 2 | 2 | — |
