Shop all MSI products
MSI PRO Z790-P WIFI DDR5 ATX Motherboard
Model: PRO Z790-PItem #: msi-pro-z790-p-wifi-13th-gen-atx-motherboard
৳28,900৳30,380Save 5%
In stockverified
Ordering is paused
We're finishing our supply arrangements. Prices and stock here are live — ordering reopens shortly.
Delivery
- Inside Dhaka
- ৳60 · 1–2 days
- Outside Dhaka
- ৳120 · 2–4 days
Sold by Micro
Key highlights
- Intel Z790 Chipset
- 4 M.2 slots
- 4x DDR5, Maximum Memory Capacity 128GB; Max. overclocking frequency:; 1DPC 1R Max speed up to 7000+ MHz; 1DPC 2R Max speed up to 6600+ MHz; 2DPC 1R Max speed up to 6400+ MHz; 2DPC 2R Max speed up to 5600+ MHz; Supports Intel XMP3.0 OC; Supports Dual-Controller Dual-Channel mode; Supports non-ECC, un-buffered memory RAM type
- ATX Form Factor; 243.84mmx304.8mm
Overview
The MSI PRO Z790-P WIFI ATX Motherboard is compatible with 14th/13th/12th Generation Intel Core, Pentium Gold, and Celeron CPUs in the LGA 1700 socket. It supports DDR5 memory, including dual-channel DDR5 7000+MHz support (OC). 14+1+1 DRPS with 55A DrMOS, twin 8-pin CPU power connections, Core Boost, Memory Boost, Enhanced Power Design, Extended heatsinks, MOSFET thermal pads rated at 7W/mK, extra choke thermal pads, and M.2 Shield Frozr are designed for high-performance systems and nonstop gaming. 6-layer PCB constructed with 2oz thicker copper and server-grade level material. This motherboard has Lightning Fast Gaming, PCIe 5.0 slots, Lightning Gen 4 x4 M.2, and USB 3.2 Gen 2x2. It contains an Intel Turbo USB 3.2 Gen 2 controller, which offers an unbroken connection with better reliability and the quickest USB rates. 2.5G LAN solution with Wi-Fi 6E, a Professional and multimedia network solution that has been upgraded. Provides a safe, reliable, and fast network connection. For the most immersive gaming experience, reward your ears with studio-grade sound quality. The MSI PRO Z790-P WIFI DDR5 13th Gen ATX Motherboard comes with a 03-year warranty.
Specifications
- Chipset
- Intel Z790 Chipset
- M.2 slots
- 4
- RAM type
- 4x DDR5, Maximum Memory Capacity 128GB; Max. overclocking frequency:; 1DPC 1R Max speed up to 7000+ MHz; 1DPC 2R Max speed up to 6600+ MHz; 2DPC 1R Max speed up to 6400+ MHz; 2DPC 2R Max speed up to 5600+ MHz; Supports Intel XMP3.0 OC; Supports Dual-Controller Dual-Channel mode; Supports non-ECC, un-buffered memory
- Form factor
- ATX Form Factor; 243.84mmx304.8mm
- Memory — Type
- DDR5
- Highlights — Model
- PRO Z790-P
- Graphics — Graphics
- 1x HDMI; 1x DisplayPort; Support HDMI 2.1 with HDR, maximum resolution of 4K 60Hz; Support DP 1.4, the maximum resolution of 4K 60Hz
- Expansion Slots — PCI
- 3x PCI-E x16 slot; 1x PCI-E x1 slot; PCI_E1 PCIe 5.0 supports up to x16 (From CPU); PCI_E2 PCIe 3.0 supports up to x1 (From the Chipset); PCI_E3 PCIe 4.0 supports up to x4 (From Chipset); PCI_E4 PCIe 3.0 supports up to x1 (From Chipset)
Show all 22 specificationsShow fewer
- Memory — Maximum Memory
- 128GB
- Connector & Ports — HDMI
- 1x HDMI 2.1
- Basic Information — Audio
- Realtek ALC897 Codec; 7.1-Channel High-Definition Audio
- Connector & Ports — Audio
- 1x Front Audio (JAUD)
- Others — Special Features
- LED FEATURE: 4x EZ Debug LED;
- Connector & Ports — USB (s)
- 4x USB 2.0 (Rear); 4x USB 2.0 (Front); 2x USB 3.2 Gen1 Type A (Rear); 4x USB 3.2 Gen1 Type A (Front); 1x USB 3.2 Gen2 Type A (Rear); 1x USB 3.2 Gen2 Type C (Front); 1x USB 3.2 Gen2x2 Type C (Rear)
- Connector & Ports — LAN Port (s)
- Intel 2.5Gbps LAN
- Basic Information — Supported CPU
- Supports 14th/13th/12th Gen Intel Core Processors, Pentium Gold, and Celeron Processors LGA 1700
- Connector & Ports — Display Port (s)
- 1x DisplayPort 1.4
- Connector & Ports — Supported Storage
- 4x M.2 slot; M.2_1 (From CPU) supports up to PCIe 4.0 x4, supports 22110/2280/2260/2242 devices; M.2_2 (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260/2242 devices; M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices; M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices; 6x SATA 6G port
- Connector & Ports — Internal I/O Ports
- 1x Power Connector(ATX_PWR); 2x Power Connector(CPU_PWR); 1x CPU Fan; 1x Pump Fan; 6x System Fan; 2x Front Panel (JFP); 1x Chassis Intrusion (JCI); 1x Front Audio (JAUD); 1x TBT connector (JTBT, supports RTD3); 1x Tuning Controller connector(JDASH); 2x Addressable V2 RGB LED connector (JARGB_V2); 1x RGB LED connector(JRGB); 4x USB 2.0; 4x USB 3.2 Gen1 Type A; 1x USB 3.2 Gen2 Type C
- Warranty Information — Manufacturing Warranty
- 3 years
- Connector & Ports — Wireless Communication module
- Intel Wi-Fi 6E; The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps; Supports 802.11 a/ b/ g/ n/ ac/ ax; Supports Bluetooth 5.2, FIPS, FISMA
- Connector & Ports — TPM (Trusted Platform Module )
- 1x TPM pin header(Support TPM 2.0)
Compare with similar products
 This itemMSI PRO Z790-P WIFI DDR5 ATX Motherboard |  GIGABYTEGIGABYTE B650M AORUS ELITE AX ICE DDR5 AMD AM5 mATX Motherboard |  MSIMSI PRO Z790-P WIFI DDR4 ATX Motherboard |  AsusAsus B850M MAX GAMING WIFI AM5 mATX Motherboard | |
|---|---|---|---|---|
| Price | ৳28,900 | ৳28,800 | ৳28,800 | ৳28,900 |
| Availability | In stock | In stock | In stock | In stock |
| Brand | MSI | GIGABYTE | MSI | Asus |
| M.2 slots | 4 | 2 | 4 | 3 |
| RAM type | 4x DDR5, Maximum Memory Capacity 128GB; Max. overclocking frequency:; 1DPC 1R Max speed up to 7000+ MHz; 1DPC 2R Max speed up to 6600+ MHz; 2DPC 1R Max speed up to 6400+ MHz; 2DPC 2R Max speed up to 5600+ MHz; Supports Intel XMP3.0 OC; Supports Dual-Controller Dual-Channel mode; Supports non-ECC, un-buffered memory | Support for DDR5 8000(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/6800(OC)/6666(OC)/6600(OC)/6400(OC)/6200(OC)/ 6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules; 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory; Dual channel memory architecture; Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules | 4x DDR4, Maximum Memory Capacity 128GB; Max. overclocking frequency:; 1DPC 1R Max speed up to 5333+ MHz; 1DPC 2R Max speed up to 4800+ MHz; 2DPC 1R Max speed up to 4400+ MHz; 2DPC 2R Max speed up to 4000+ MHz; Supports Dual-Channel mode Supports non-ECC, un-buffered memory; Supports Intel Extreme Memory Profile (XMP) | Supports up to 8000+MT/s (OC) with Ryzen 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC Un-buffered DIMM; Dual channel memory architecture; Supports AMD Extended Profiles for Overclocking (EXPO); ASUS Enhanced Memory Profile (AEMP) |
| Form factor | ATX Form Factor; 243.84mmx304.8mm | Micro ATX Form Factor; 24.4cm x 24.4cm | ATX Form Factor; 243.84mmx304.8mm | mATX Form Factor; 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm) |
| Chipset | Intel Z790 Chipset | AMD B650 | INTEL Z790 | AMD B850 Chipset |
